China ODM OEM Rare Earth Rustproof High Performance Permanent Magnet Coupling High Torque for sale

ODM OEM Rare Earth Rustproof High Performance Permanent Magnet Coupling High Torque

Price Negotiable

Price: Negotiable

MOQ: 1PCS

Delivery Time: 30 work days

Brand: HSMAG

Product Description

Coupling Accessories, Strong SmCo Permanent Magnets, Ring, Block, Cylinder Magnets, Rare Earth Magnet, Sliver

The Main Products

SmCo (Samarium Cobalt) permanent magnet

Samarium cobalt magnets can work at a high temperature of 350 ° C, and have the advantages of high magnetic properties, excellent temperature characteristics and corrosion resistance, and are widely used in aerospace, electronic instruments, magnetic pumps, high temperature lamps, sensors and other fields. This magnet can be made in different shapes (round, square, ring, tile, bread) Our company accepts custom shapes and sizes from customers.

Shape	Ring, Disk, Cube, Loaf, Segment,custom
Process	Melting, Crushing, Milling, Machining, Sintering, Pressing, Alignment in Magnetic Fisld, Magnetizing.
Core Technologies	Composition Controlling Technologies Powder Controlling Technologies Mold Design Technologies Crystal particles Ailgnment Technologies Applied magnetic Technologies Magnetization Technologies
Inspection procedure	Raw material inspection Granularity inspection Green compact inspection Roughcast inspection Magnetic property inspection Dimensions inspection


			1:5 SmCo Magnet
SmCo5(25 MGOe)

			SmCo1:5 Magnet is also called SmCo5, the highest working enviorment can be 250℃.Based on Sm,Co and some other metals. After processing of melting, milling, compression moulding and sintering. To make work blank with different levels of performance

			2:17 SmCo Magne
Sm2Co17 (32 MGOe)

			SmCo2:17 Magnet is also called Sm2Co17, the highest working can be 350℃.Based on Sm, Co, copper, iron zirconium and some other metals. After processing of melting, milling, compression moulding and sintering. To make work blank with different levels of performance.

Sm	23-28%
Co	48-52%
Fe	14-17%
Cu	5-7%
Zr	2-3%

Products Description

1:5 SmCo Magnet

SmCo1:5 Magnet is also called SmCo5, the highest working enviorment can be 250℃.Based on Sm,Co and some other metals. After processing of melting, milling, compression moulding and sintering. To make work blank with different levels of performance.

2:17 SmCo Magnet

SmCo2:17 Magnet is also called Sm2Co17, the highest working can be 350℃.Based on Sm, Co, copper, iron zirconium and some other metals. After processing of melting, milling, compression moulding and sintering. To make work blank with different levels of performance.

Product Name	SmCo Magnet
Material	SmCo Magnet (Sm2Co17, SmCo5)
Normal size range	W=3-130mm,H=1.5-100mm,L=1-130mm
Biggest size	According to your needs
Smallest size	According to your needs
Note:	For large bread products, no thin size is allowed, because SmCo's huge brittleness will easily cause breakage during assembly

Froperties of SmC0 Magnets

Dimensions anf Toleranfces

Company Profile

Mianyang Hengxin Magnetic Materials Co., Ltd. was founded in 1999, specializing in the manufacture and development of sintered samarium cobalt permanent magnet materials and devices; after years of development, it has formed a production capacity of 500 tons of samarium cobalt permanent magnet materials per year, and is the main manufacturer of samarium cobalt permanent magnet materials and devices in China.
