China Carbon Stainless Steel Optical Fiber Laser Cutting Machine for sale

Carbon Stainless Steel Optical Fiber Laser Cutting Machine

Price Negotiable

Price: 14500-19000usd

MOQ: 1set

Delivery Time: 10-20 working days

Brand: DWIN

Product Description

fiber optic laser cutting machine price for carbon stainless steel

Features

The cutting machine adopts international famous brand advanced laser, which has high electro-optical efficiency, water-saving and power-saving. Especially important, it can be free of maintenance for a long time, save a lot of maintenance funds and time, and improve work efficiency.

The overall main frame adopts gantry structure worktable. The high damping bed has good rigidity, high precision and stable operation. The frame structure is made of high-quality steel honeycomb welding. The machine tool is annealed, twice aged and processed by large-scale gantry milling machine. These design and processing means ensure that the machine tool has excellent seismic resistance, high rigidity and stability. It fully meets the stability requirements of the machine tool in high-speed motion.

The high precision double side rack and pinion drive and linear guide rail are adopted, and the powerful dual drive servo motor drive system is used to effectively ensure the speed and accuracy of laser cutting.

Technical parameter:

MODEL	DW3015F
Function	METAL PLATE CUTTING
Laser power	800W/1000W/1500/2000/3000W
Working area	1500mmX3000mm / 2000mmX4000mm / 2000mmmX6000mm
Transmission system	Gear + Rails
MAX CUTTING SPEED	60m/min
X.Y axis location accuracy	±0.01mm
X.Y axis repeat location accuracy	±0.01mm
Cutting thickness	Detailed in the following cutting thickness
Machine size	4800X2280X2300MM
Guiderail Brand	HIWIN
Cutting Thickness	0-30mm
Cutting Speed	0-60m/min
Cutting Area	1500mm*3000mm
Applicable Material	Metal
