PFalcon-640 Thermal Monocular Night Vision Infrared Thermal Imaging 350 G
Maintenance
1. After observing or after a long time without observing the target, you should turn off the camera in time to prolong the working time of the multi-purpose monocular night vision device.
2. The lens is an important optical component, during installation and use, avoid staining and damaging the surface of the lens with oil and various chemicals, and cover the lens after use.
3. When not in use and during transport, remove the batteries and place the Monocular Night Vision in its case.
4. When storing or not working for a long period of time, store the Monocular Night Vision in a cool, dry environment.
5. Do not use chemical solvents, thinners etc. to scrub the case, but use a clean, soft, dry flannel cloth.
6. The lens of the multi-purpose monocular night vision device should only be cleaned when it is visibly soiled.
7. When not in use for a long time, the lens should be checked and calibrated every six months.
| Product name | PFalcon-640 Multi-purpose monocular night vision device |
| Detector |
640×512/12μm |
| Objective lens | f25mm/F1.0 |
| Recognize of person | 590mm |
| Recognize of vehicle | 1000m |
| Frame rate | 50Hz |
| FOV |
17.5°×14° |
| Ocular Lens | 14* |
| Battery life | ≥6h |
| Display |
0.39时OLED |
| Exit pupil diameter | Collimator Lens ≥15mm Ocular Lens 5mm |
| Exit pupil distance | Collimator Lens ≥8mm Ocular Lens 20mm |
| Diopter | -4~4 |
| Interface | Picatinny Rail,Helmet mount |
| Weight | 350g |
| Dimensions |
105×65×48(mm) |
| IPrating | IP67 |
| Operating temperature |
-45℃~55℃ |
| Storage temperature | -55℃~70℃ |
Established in 2021, Trading Co., Ltd. is a supplier of high-quality outdoor clothing, outdoor equipment supplies and military quality civil products.
2. Export country of the company:
It is mainly aimed at the global outdoor products market and WG group.
3. Functions that can be brought to customers:
Provide excellent military quality outdoor supplies and equipment.
4. Company services:
What we offer:
1) Good quality control
2) Highly competitive prices
3) state-of-art technology products
4) Best professional team of lifestyle consumer electronics.
5) Smooth communication
B) Sample time? Existing items: Within 15-20 days.
C) Whether you could make our brand on your products? Yes. We can print your Logo on both the products and the packages if you can meet our MOQ.
D) Whether you could make your products by our color? Yes, The color of products can be customized if you can meet our MOQ.
E) How to guarantee the quality of your products? 1) Strict detection during production. 2) Strict sampling inspection on products before shipment and intact product packaging ensured.
