Indoor Fixed Fine Pixel Pitch Led Display Video Wall P0.9 P1.2 P1.5 P1.8

 Indoor Fixed Fine Pixel Pitch Led Display Video Wall P0.9 P1.2 P1.5 P1.8

Advantages


1. High Precision: all-in-one design with die-casting aluminum fashioning tech

2. 100% Front Maintenance:all components dismount from front side, fast and easy

3. Wireless Connection: adopt hard-wired connector, support hot plug to dismounting easily

4. Fast Heat Dissipation: multi-point heat emission holes speed up efficiency of heat dissipation

Applications:

Small Pixel LED display are widely used in different applications, the main application fields

are command and dispatch center, security monitoring, video conference, exhibition, radio and

television studio, meteorological information center, production safety monitoring, environment

monitoring, fire protection, maritime flood control, energy, electric power, finance, securities market,

shopping malls, hotels, airports, subway and so on











Specifications
Pixel pitch(mm)	0.93	1.25	1.56	1.87
Density(M2)	1137777	640000	409600	284444
Brightness(nits/m2)	500	600	700	800
Work environment	Indoor	Indoor	Indoor	Indoor
Temperature	-30°C~ 60°C	-30°C~ 60°C	-30°C~ 60°C	-30°C~ 60°C
Viewing Angle	H:160  V:160°	H:160 V:160°	H:160 V:160°	H:160 V:160°
Module Size(mm)	150x168.75	150x168.75	150x168.75	150x168.75
Cabinet Size (mm)	600x337.5	600x337.5	600x337.5	600x337.5
Cabinet thickness	38	38	38	38
IP Rating	IP34	IP34	IP34	IP34
Average Power(W/m2)	180	225	225	225
Refresh Rate	>3840	>3840	>3840	>3840
Cabinet Weight(kg)	5	5	5	5





FAQ :

A 1, Who is Longvision?

Q1, Based in Shenzhen, Longvision is an professional OEM/ODM-led display factory, our products are sold to more than 130 countries and regions all over the world.


A2, Can I get a sample order?
Q2, Yes, warmly welcome. Strong partnerships are the result of every small trial. Price would be negotiated welcome based on bigger quantity.


A3, How does Longvision do regarding quality control?
Q3, "Quality is the foundation of an enterprise" that's our faith. Our factory has gained CE, FCC, RoHS, and other certifications.


A4, What is your after-sales service?
Q4, We offer 100% guarantee on our product and 24hrs non-stop service, you can find us for technology help anytime. We have
professional engineers who can speak English.


A5, When will you make the delivery?
Q5, We can deliver the goods within 7~15 working days according to the size of your projects.
