Sumitomo 480 Demolition Boom Q355B Material 26 Meters High Reach

Price Negotiable

Price: $24000.00/Pieces

MOQ: 1set

Delivery Time: 15works

Brand: ZH

Product Description

The most favorable price sumitomo480 excavator 26meters high reach demolition arm and boom

The beauty of the demolition boom is its ease of positioning and flexibility in the maneuvering of tools in carrying out primary and secondary demolition jobs safely. ZH HEAVY attachments are engineered for performance, reliability and low total cost of ownership in mind. As we fully understand the harsh working conditions, hence only quality steel is used in the fabriion. Demolition booms for excavators greater than 120 metric tons (264,000 lbs) will have a detachable and modular main boom with a quick coupling joint for efficient mounting and dismantling, as well as ease of ground handling and transportation.

The High Reach Demolition Boom are designed for the following appliions:

Demolishing high-rise buildings and structures.
Typically attached to a hydraulic breaker, multi-processor or hydraulic shear.

Features:

Use of high strength steel for increased reliability.
Design is simulated extensively, ensuring design integrity and detecting potential stress and fatigue points.
Hydraulic operated modular joint on main boom, ease of detaching for transportation.
Cylinders installed with load hold safety valves.

We do undertake entire turnkey solutions in which we convert your existing excavator to a full-fledged demolition equipment. The customized conversion is not restricted to the following:

Widening and lengthening of existing undercarriage.
Addition of an extra hydraulic control system.
Modifiion of cabin into articulating or tilting
cabin.
Cabin protection guard system.
Integrated counterweight.
Full commissioning of newly converted machine.

WORK ENVIRONMENT SAFETY

With the greater emphasis on work environment safety and stricter regulation in the industry, high reach demolition booms are fast becoming the choice of attachment for demolishing old buildings, replacing the traditional and more accident prone practice where excavators were lifted onto the building to carry out the highly risky tasks. The demolition boom has changed the entire concept of tearing down buildings, not only improving the overall safety standard, but also extending the working radius and reach of the front end attachment.

We provide complete Package include

egory	model	Part Length	Total length(m)	weight(kg)	Maximum removal height(m)
Boom	25T	8.5	16	2800	16M
Middle arm		2.3		900
Arm		5.2		1700
Boom	30T	9.5	18	3000	18M
Middle arm		2.3		1000
Arm		5.2		1950
Boom	35T	10.5	20	3500	20M
Middle arm		2.3		1100
Arm		7.2		2400
Boom	40T	11.5	22	4000	22M
Middle arm		2.4		1200
Arm		8.1		2800
Boom	45T	12.5	24	4400	24M
Middle arm		2.4		1300
Arm		9.1		3000
Boom	50T	13.5	26	4800	26M
Middle arm		2.4		1400
Arm		9.1		3200
Boom	60T	14.5	28	5200	28M
Middle arm		2.4		1500
Arm		11.1		3400
