Product Description
BTPS Hydraulic Directional Control Solenoid valve 4WE series 4WE6 4WE6D 4WE6D62/EG24N9K4 R900561274 hydraulic valve
Factory sale Rexroth Valves 4WE6A 4WE6B 4WE6C 4WE6D 4WE6E 4WE6F 4WE6J 4WE6H 4WE6G 4WE6L 4WE6M 4WE6 4WE10 Hydraulic Valve
|
Parameter
|
Data
|
||
|
Weight
|
Valve with a coil(kg)
|
Single connection
|
Centering connection
|
|
3.9
|
4.0
|
||
|
Valve with two coils(kg)
|
5.5
|
5.6
|
|
|
Installation loion
|
Arbitrary
|
||
|
Ambient temperature range
|
Standard model (℃)
|
-20⋯+70(NBR seal) -15⋯+70 (FKM seal)
|
|
|
Models suitable for HFC hydraulic oil(℃)
|
-20⋯+50
|
||
|
Low temperature model(℃)
|
-40⋯+50
|
||
|
Storage temperature range(℃)
|
-20⋯+50
|
||
|
Maximum operating pressure
|
Port A, B, P(bar)
|
350
|
|
|
Port T(bar)
|
210
|
||
|
Maximum flow(l/min)
|
160
|
||
|
Hydraulic oil temperature range (at the valve working port)(℃)
|
–20 … +80 (NBR seal)
|
||
|
–15 … +80 (FKM seal)
|
|||
|
–20 … +50(HFC hydraulic oil)
|
|||
|
–40 … +50(Low temperature model)
|
|||
|
Viscosity range(mm2/s)
|
2.8 … 500
|
||
Rexroth hydraulic valve
A hydraulic valve is an automation component operated by pressure oil. It is controlled by a pressure distribution valve and
pressure oil. It is usually used in combination with an electromagnetic pressure distribution valve. It can be used to remotely
control the on and off of the oil, gas, and water pipeline systems of hydropower stations. Commonly used for clamping, control,lubriion and other oil circuits. There are direct-acting type and pilot type, and the pilot type is mostly used.
pressure oil. It is usually used in combination with an electromagnetic pressure distribution valve. It can be used to remotely
control the on and off of the oil, gas, and water pipeline systems of hydropower stations. Commonly used for clamping, control,lubriion and other oil circuits. There are direct-acting type and pilot type, and the pilot type is mostly used.
Hydraulic valve design principle
The design of the hydraulic valve is mainly for the design of the hydraulic valve group, and the oil circuit must be considered before the design of the hydraulic valve group. It is necessary to determine in advance which parts of the oil circuit can be integrated. The design of the oil circuit must be simple and save Go unnecessary steps. After determining the oil circuit, the main thing is the oblique hole and the process hole. These things in the oil path should be reduced. As long as it is enough, it
is not necessary too much. Pay attention to the hole diameter in the design of the oblique hole and the process hole.
is not necessary too much. Pay attention to the hole diameter in the design of the oblique hole and the process hole.
|
Collecting valve
|
Proportional valve
|
Maintaining valve
|
|
Throttle valve
|
Relief valve
|
Solenoid directional valve
|
|
Speed regulation valve
|
Pressure reducing valve
|
Manual reversing valve
|
|
Drive valve
|
Pressure valve
|
Check valve
|
|
Flow valve
|
Cartridge valve
|
Hydraulic control one-way valve
|
|
Collecting valve
|
Stop valve
|
Solenoid valve
|
|
Pilot valve
|
Reverse check valve
|
Superposition valve
|
|
Direct acting relief valve
|
Pilot check valve
|
Directional valve
|
|
Pilot relief valve
|
Sequence valve
|
Pilot sequence valve
|
|
Pilot reducing valve
|
Balance valve
|
Direct acting sequence valve
|
Features
▶ High-power solenoid
▶ Porting pattern according to DIN 24340 form A
▶ Porting pattern according to ISO 4401-03-02-0-05 andNFPA T3.5.1 R2-2002 D03
▶ Wet-pin DC or AC solenoids with detachable coil
▶ Solenoid coil can be rotated by 90°
▶ The coil can be changed without having to open thepressure-tight chamber
▶ Electrical connection as individual or central connection
▶ Manual override, optional
▶ Spool position monitoring, optional
High Performance Replacement Reexroth Hydraulic Pump Solenoid valve Directional Control Valve 4WE6062-EG24N9K4
The Hydraulic Solenoid Operated Selector Valves come in both 12VDC and 24VDC. These valves come with a nominal flow of either
50LPM or 90LPM and have a maximum pressure of 315 bar.
---- Stack up to 3 sections (A,B type)
----12V/24V DC optional
----3-pin or 2-pin water-proof plug optional
