Rexroth Hydraulic Pump A4VG180 piston pump A4VG180EP4DT1/32L-NSD02F041DP hydraulic pump assembly
Rexroth Hydraulic Pump A4VG180 piston pump A4VG180EP4DT1/32L-NSD02F041DP hydraulic pump assembly
Table of values
| Size | 40 | 60 | 75 | 95 | 130 | 145 | 190 | 260 | 130 | 145 | 190 | 260 | |||
| Version | Standard | With charge pump | |||||||||||||
| Displacement geometric, per revolution |
Vg max | cm³ | 42 | 58.5 | 74 | 93.5 | 130 | 145 | 193 | 260 | 130 | 145 | 193 | 260 | |
| Nominal pressure | pnom | bar | 350 | 350 | 350 | 350 | 350 | 350 | 350 | 350 | 350 | 350 | 350 | 350 | |
| Maximum pressure | pmax | bar | 400 | 400 | 400 | 400 | 400 | 400 | 400 | 400 | 400 | 400 | 400 | 400 | |
| Maximum speed | at Vg max | nnom | rpm | 3000 1) | 2700 1) | 2550 1) | 2350 1) | 2100 1) | 2200 1) | 2100 1) | 1800 1) | 2500 2) | 2500 2) | 2500 2) | 2300 2) |
| Flow | at Vg max and nnom | qV nom | l/min | 126 | 158 | 189 | 220 | 273 | 319 | 405 | 468 | 325 | 363 | 483 | 598 |
| Power | at qV nom and pnom | P | kW | 74 | 92 | 110 | 128 | 159 | 186 | 236 | 273 | 190 | 211 | 281 | 349 |
| Torque | at Vg max and pnom | M | Nm | 234 | 326 | 412 | 521 | 724 | 808 | 1075 | 1448 | 724 | 808 | 1075 | 1448 |
| Weight (approx.) | m | kg | 32 | 40 | 45 | 53 | 66 | 76 | 95 | 125 | 72 | 73 | 104 | 138 | |
A4VG28EP4D1/32L-NSC10F004ST
A4VG40EZ2DM1/32R-NSC02F005DP
A4VG56DWDMT1/32R-NSC02F013P-S
A4VG56EZ2DM1/32R-NSC02F023SP
A4VG71EP4DT1/32R-NAF02F011DP
A4VG71DWDMT1/32R-NSF02F011P-S
A4VG90EP4D1/32L-NAF02F041FP
A4VG90EP4DT1/32R-NZF02F021DH
A4VG125EP3D1/32L-NSF02F071FP
A4VG125DA2D8/32R-NAF02F001DQ
A4VG125EP4D1/32R-NSF02F021DP
A4VG125HD9MT1/32R-NSF02F021S-S
A4VG125EP4DT1/32L-NZF02F001DP
A4VG125HD9MT1/32R-NSF02F691S
A4VG125EP4D1/32L-NAF02F691DP
A4VG125EP4D1/32R-NAF02F691DP
A4VG180DA2D2/32L-NSD02F001DT
A4VG180HD9MT1/32R-NZD02F721S-S
A4VG180HD9MT1/32R-NSD02F021S-S
A4VG180EP4DM1/32L-NZD02K07XEP
AA4VG180EP31/32L-NSDXXFXX1FC-S
A4VG180EP4DT1/32RL-NZD02F011ST
A4VG180EP4D1/32L-NSD02F001SP
A4VG250EP4DT1/32R-NSD10F021DP
A4VG250EP4D1/32R-NTD10F691DP
A4VG250EP4D1/32R-NTD10F721DH
