4WEH10J4X_6EG24N9ETK4B10 Rexroth Type 4WEH10 Directional Spool Valves Rexroth
Price:
Negotiation
MOQ:
1
Delivery Time:
5 work days
Brand:
BTPS
Product Description
Type 4WEH Directional Spool Valves, Pilot Operated, With electro-hydraulic Actuation
Size 10, 16, 25 (WEH22), 25 (WEH25), 32
Component series 4X, 7X, 6X
Maximum operating pressure 280 bar
Maximum flow 1100 l/min
Features:
- Types of actuation (internal or external pilot control): Electro-hydraulic (type WEH)
- For subplate mounting
- Porting pattern according toISO 4401
- 4/3-, 4/2- or 3/2-way version
- Spring or pressure centering, spring end position or hydraulic end position
- Wet-pin DC or AC solenoids, optional
- Electrical connection as individual or central connection
- Optional versions:
- Manual override
- Switching time adjustment
- Preload valve in channel P of the main valve
- Stroke setting and/or spool position monitoring
Rexroth hydraulic valve
A hydraulic valve is an automation component operated by pressure oil. It is controlled by a pressure distribution valve and
pressure oil. It is usually used in combination with an electromagnetic pressure distribution valve. It can be used to remotely
control the on and off of the oil, gas, and water pipeline systems of hydropower stations. Commonly used for clamping, control,lubriion and other oil circuits. There are direct-acting type and pilot type, and the pilot type is mostly used.
pressure oil. It is usually used in combination with an electromagnetic pressure distribution valve. It can be used to remotely
control the on and off of the oil, gas, and water pipeline systems of hydropower stations. Commonly used for clamping, control,lubriion and other oil circuits. There are direct-acting type and pilot type, and the pilot type is mostly used.
Type code
| 01 | 02 | 03 | 04 | 05 | 06 | 07 | 08 | 09 | 10 | 11 | 12 | 13 | 14 | 15 | 16 | 17 | 18 | 19 | 20 | 21 | 22 | ||
| WEH | / | K4 | / | * |
| 01 | up to 280 bar | no code |
| 02 | 3-way version | 3 |
| 4-way version | 4 | |
| Types of actuation | ||
| 03 | electro-hydraulic | WEH |
| Size | ||
| 04 | NG10 | 10 |
| NG16 | 16 | |
| NG25 (version "WEH 22") | 22 | |
| NG25 (version "WEH 25") | 25 | |
| Size 32 | 32 | |
| Spool return in the main valve | ||
| 05 | by means of springs | no code |
|
hydraulic 1) |
H | |
| 06 | Symbols; for the possible version, see "Symbols/Circuit diagrams" | |
| 07 | Component series 40 … 49 (40 … 49: unchanged installation and connection dimension) – NG10 | 4X |
| Component series 60 … 69 (60 … 69: unchanged installation and connection dimension) – NG25 ("WEH 25") and NG32 | 6X | |
| Component series 70 … 79 (70 … 79: unchanged installation and connection dimension) – NG16 (from series 72) andNG25 ("WEH 22") | 7X | |
| Control spool return in the pilot control valve with 2 spool positions and 2 solenoids (only possible with symbols C, D, K, Z and hydraulic control spool return in the main valve) | ||
| 08 | With spring return | no code |
| Without spring return | O | |
|
Without spring return with detent 2) |
OF | |
|
Pilot control valve 2) |
||
| 09 | High-power valve | 6E |
| 10 |
Direct voltage 24 V 2) |
G24 |
|
Alternating voltage 230 V, 50/60 Hz 2) |
W230 | |
| For other voltages, frequencies and electric data, see data sheet of high-power valve | ||
| 11 | Without manual override | no code |
| With manual override | N | |
| With concealed manual override | N9 | |
| Pilot oil flow | ||
| 12 |
External pilot oil supply, external pilot oil return 3) |
no code |
|
Internal pilot oil supply, external pilot oil return 3; 4) |
E | |
|
Pilot oil supply internal, pilot oil return internal 4) |
ET | |
|
External pilot oil supply, internal pilot oil return 3) |
T | |
| version “ET” and “T” with 3-spool position valve, pressure-centered, only possible if ppilot ≥ 2 x ptank + ppilot min!) | ||
| Switching time adjustment | ||
| 13 | without switching time adjustment | no code |
| Switching time adjustment as supply control | S | |
| Switching time adjustment as discharge control | S2 | |
| Corrosion resistance | ||
| 14 | None (valve housing primed) | no code |
| Improved corrosion protection (240 h salt spray test according to EN ISO 9227) | J3 | |
|
Electrical connection 2) |
||
| 15 | Individual connection | |
| Without mating connector; connector DIN EN 175301-803 | K4 6) | |
| For further electrical connections, see data sheet 23178 and 08010 | ||
| Spool position monitoring | ||
| 16 | Without position switch | no code |
| Monitored spool position "a" | QMAG24 | |
| Monitored spool position "b" | QMBG24 | |
| Monitored spool position "a" and "b" | QMABG24 | |
| Monitored rest position | QM0G24 | |
| Stroke setting | ||
| 17 | For ordering code, see stroke setting | |
|
Throttle insert 2) |
||
| 18 | Without throttle insert | no code |
| Throttle Ø 0.8 mm | B08 | |
| Throttle Ø 1.0 mm | B10 | |
| Throttle Ø 1.2 mm | B12 | |
| Throttle Ø 1.5 mm | B15 | |
| Throttle Ø 2.0 mm | B20 | |
| Throttle Ø 2.5 mm | B25 | |
|
preload valve (not for NG10) 2) |
||
| 19 | without preload valve | no code |
| with preload valve (pö = 4.5 bar) | P4,5 | |
| 20 | without pressure reducing valve | no code |
| with pressure reducing valve | D3 5) | |
| Seal material | ||
| 21 | NBR seals | no code |
| FKM seals | V | |
| Observe compatibility of seals with hydraulic fluid used. (Other seals upon request) | ||
| 22 | Further details in the plain text | * |
Hydraulic valve design principle
The design of the hydraulic valve is mainly for the design of the hydraulic valve group, and the oil circuit must be considered before the design of the hydraulic valve group. It is necessary to determine in advance which parts of the oil circuit can be integrated. The design of the oil circuit must be simple and save Go unnecessary steps. After determining the oil circuit, the main thing is the oblique hole and the process hole. These things in the oil path should be reduced. As long as it is enough, it
is not necessary too much. Pay attention to the hole diameter in the design of the oblique hole and the process hole.
is not necessary too much. Pay attention to the hole diameter in the design of the oblique hole and the process hole.
|
Collecting valve
|
Proportional valve
|
Maintaining valve
|
|
Throttle valve
|
Relief valve
|
Solenoid directional valve
|
|
Speed regulation valve
|
Pressure reducing valve
|
Manual reversing valve
|
|
Drive valve
|
Pressure valve
|
Check valve
|
|
Flow valve
|
Cartridge valve
|
Hydraulic control one-way valve
|
|
Collecting valve
|
Stop valve
|
Solenoid valve
|
|
Pilot valve
|
Reverse check valve
|
Superposition valve
|
|
Direct acting relief valve
|
Pilot check valve
|
Directional valve
|
|
Pilot relief valve
|
Sequence valve
|
Pilot sequence valve
|
|
Pilot reducing valve
|
Balance valve
|
Direct acting sequence valve
|
| R978902151 | 4WEH10C4X/6EG24N9ETK4 |
| R978899768 | 4WEH10C4X/6EG24N9K4 |
| R978905849 | 4WEH10C4X/6EG24N9K4/B12 |
| R978910361 | 4WEH10C4X/6EG24N9TK4/B10V |
| R978907975 | 4WEH10C4X/6EG24N9TS2K4 |
| R978909293 | 4WEH10C4X/6EW110N9ETK4 |
| R978911435 | 4WEH10C4X/6EW110N9ETSK4 |
| R978908691 | 4WEH10C4X/6EW110N9S2K4/V |
| R978911369 | 4WEH10C4X/OF6EW110N9K4/B06 |
| R978906995 | 4WEH10D4X/6EG24N9ETK4/12 |
| R978902730 | 4WEH10D4X/6EG24N9ETK4/B10 |
| R978906366 | 4WEH10D4X/6EG24N9ETS2K4/B10 |
| R978897210 | 4WEH10D4X/6EG24N9K4/V |
| R978900447 | 4WEH10D4X/6EG24N9TK4 |
| R978914655 | 4WEH10D4X/6EW110N9ES2K4 |
| R978910727 | 4WEH10D4X/6EW110N9ETD/B12 |
| R978905711 | 4WEH10D4X/6EW110N9ETK4/12B10V |
| R978916537 | 4WEH10D4X/6EW110N9ETK4/B08V |
| R978907146 | 4WEH10D4X/6EW110N9ETK4/B10 |
| R978911817 | 4WEH10D4X/6EW110N9ETK4/B10 |
| R978908375 | 4WEH10D4X/6EW110N9ETK4/B10V |
| R978908379 | 4WEH10D4X/6EW110N9ETS2K4/B10 |
| R978901735 | 4WEH10D4X/6EW110N9ETSK4 |
| R978909328 | 4WEH10D4X/6EW110N9K4/10 |
| R978908591 | 4WEH10D4X/6EW110N9K4/B10 |
| R978910367 | 4WEH10D4X/6EW110N9TK4 |
| R978917151 | 4WEH10D4X/6EW110N9TK4/V |
| R978910527 | 4WEH10D4X/6EW110N9TS2K4/V |
| R978910388 | 4WEH10D4X/6EW110NETK4/B10V |
| R978913847 | 4WEH10D4X/O6EG24N9K4 |
| R978910227 | 4WEH10D4X/O6EW110N9K4 |
| R978917243 | 4WEH10D4X/OF6EG24N9ETK4/V |
| R978910068 | 4WEH10D4X/OF6EW110N9EK4 |
| R978911871 | 4WEH10D4X/OF6EW110N9ETK4/V |
| R978908706 | 4WEH10D4X/OF6EW110N9ETS2K4 |
| R978909871 | 4WEH10D4X/OF6EW110N9K4 |
| R978910028 | 4WEH10D4X/OF6EW230N9ETK4 |
| R978899592 | 4WEH10E4X/6EG24N9EK4 |
| R978907590 | 4WEH10E4X/6EG24N9EK4/B10 |
| R978908052 | 4WEH10E4X/6EG24N9EK4/B10V |
| R978908383 | 4WEH10E4X/6EG24N9ESK4/B10 |
| R978910871 | 4WEH10E4X/6EG24N9ETK4/B10V |
| R978901194 | 4WEH10E4X/6EG24N9ETK4/V |
| R978905450 | 4WEH10E4X/6EG24N9ETS2K4/B10 |
| R978907393 | 4WEH10E4X/6EG24N9ETSK4/B10 |
| R978900398 | 4WEH10E4X/6EG24N9K4 |
| R978897349 | 4WEH10E4X/6EG24N9K4/V |
| R978912674 | 4WEH10E4X/6EW110N9ESK4 |
| R978905823 | 4WEH10E4X/6EW110N9ETK4/10B10V |
| R978906336 | 4WEH10E4X/6EW110N9ETK4/B10 |
| R978911140 | 4WEH10E4X/6EW110N9ETK4/B10H10 |
| R978911192 | 4WEH10E4X/6EW110N9ETK4/B10N10 |
| R978910759 | 4WEH10E4X/6EW110N9ETK4/V |
| R978910854 | 4WEH10E4X/6EW110N9ETS2K4 |
| R978907128 | 4WEH10E4X/6EW110N9ETS2K4/B10 |
| R978910715 | 4WEH10E4X/6EW110N9ETSK4 |
| R978905404 | 4WEH10E4X/6EW110N9ETSK4/B10 |
| R978916266 | 4WEH10E4X/6EW110N9K4/B08 |
| R978916322 | 4WEH10E4X/6EW110N9S2K4 |
| R978910863 | 4WEH10E4X/6EW110N9TK4 |
| R978916172 | 4WEH10E4X/6EW110NETS2K4/V |
| R978909622 | 4WEH10E4X/6EW230N9EK4/B10 |
| R978908127 | 4WEH10E4X/6EW230N9K4/B10 |
| R978910806 | 4WEH10E4X/E |
| R978899735 | 4WEH10EA4X/6EG24N9ETK4 |
| R978910525 | 4WEH10EA4X/6EG24N9ETK4/B10 |
| R978912144 | 4WEH10EA4X/6EG24N9ETK4/V |
| R978896770 | 4WEH10EA4X/6EG24N9TK4 |
| R978916340 | 4WEH10EA4X/6EW110N9EK4/V |
| R978912741 | 4WEH10EA4X/6EW110N9ETK4 |
| R978908771 | 4WEH10EB4X/6EG24N9ETK4/V |
| R978904920 | 4WEH10EB4X/6EG24N9K4 |
| R978907109 | 4WEH10EB4X/6EG24N9K4/B10 |
| R978910320 | 4WEH10EB4X/6EG24N9S2K4 |
| R978910132 | 4WEH10EB4X/6EW110N9EK4 |
| R978909074 | 4WEH10EB4X/6EW110N9ETK4/B10 |
| R978914651 | 4WEH10EB4X/6EW110N9ETK4/V |
| R978908775 | 4WEH10EB4X/6EW110N9ETS2K4 |
| R978912852 | 4WEH10EB4X/6EW110N9K4 |
| R978902198 | 4WEH10F4X/6EW110N9TK4 |
| R978910380 | 4WEH10G4X/6EG24N9EK4 |
| R978902187 | 4WEH10G4X/6EG24N9ETK4 |
| R978897302 | 4WEH10G4X/6EG24N9ETK4/B10 |
| R978904750 | 4WEH10G4X/6EG24N9K4 |
| R978908962 | 4WEH10G4X/6EW110N9EK4 |
| R978911581 | 4WEH10G4X/6EW110N9ETK4 |
| R978901446 | 4WEH10G4X/6EW110N9K4 |
| R978908404 | 4WEH10G4X/6EW110N9K4/B10SO887 |
| R978914938 | 4WEH10G4X/6EW110N9S2K4 |
| R978911101 | 4WEH10G4X/6EW110N9TK4 |
| R978910156 | 4WEH10G4X/6EW110N9TS2K4 |
| R978916233 | 4WEH10GA4X/6EG24N9K4 |
| R978911701 | 4WEH10GA4X/6EW110N9ETK4 |
| R978911858 | 4WEH10GA4X/6EW110N9K4 |
| R978909072 | 4WEH10GA4X/6EW110N9TK4 |
| R978899383 | 4WEH10H4X/6EG24N9TK4 |
| R978911400 | 4WEH10H4X/6EW110N9EK4 |
| R978901584 | 4WEH10H4X/6EW110N9ETK4 |
| R978900617 | 4WEH10H4X/6EW110N9TK4 |
| R978907595 | 4WEH10HA4X/6EG24N9TK4 |
| R978914672 | 4WEH10HC4X/6EW110N9K4 |
| R978909406 | 4WEH10HD4X/6EG24N9EK4 |
| R978911285 | 4WEH10HD4X/6EG24N9ETK4 |
| R978901606 | 4WEH10HD4X/6EG24N9ETK4/10 |
| R978912413 | 4WEH10HD4X/6EW110N9EK4/B10 |
| R978913065 | 4WEH10HD4X/6EW110N9ETSK4 |
| R978912162 | 4WEH10HD4X/6EW110N9K4 |
| R978911959 | 4WEH10HD4X/6EW110N9K4/B08 |
| R978914941 | 4WEH10HD4X/6EW110N9K4/B10 |
| R978916050 | 4WEH10HD4X/6EW110N9TK4/V |
| R978910225 | 4WEH10HD4X/6EW230N9ES2K4 |
| R978914236 | 4WEH10HD4X/O6EG24N9K4 |
| R978900625 | 4WEH10HD4X/OF6EG24N9ETK4 |
| R978908320 | 4WEH10HD4X/OF6EG24N9ETK4/B20 |
| R978904745 | 4WEH10HD4X/OF6EG24N9ETS2K4/B10 |
| R978911055 | 4WEH10HD4X/OF6EG24N9ETSK4/B10 |
| R978912748 | 4WEH10HD4X/OF6EW110N9EK4/B08 |
| R978908579 | 4WEH10HD4X/OF6EW110N9ETS2K4/B10 |
| R978916074 | 4WEH10HD4X/OF6EW110N9ETSK4 |
| R978909998 | 4WEH10HK4X/OF6EG24N9ETK4 |
| R978905135 | 4WEH10HK4X/OF6EG24N9ETK4/B08 |
| R978909942 | 4WEH10HK4X/OF6EG24NETK4 |
| R978912365 | 4WEH10HK4X/OF6EG24NETK4/V |
| R978917091 | 4WEH10HY4X/6EW110N9ETS2K4 |
| R978906793 | 4WEH10HY4X/6EW110N9K4 |
| R978909633 | 4WEH10HZ4X/OF6EG24N9K4/B06 |
| R978912314 | 4WEH10HZ4X/OF6EW110N9K4/B06 |
| R978909362 | 4WEH10J4X/6EG110N9EK4/B08V |
| R978906992 | 4WEH10J4X/6EG24N9EK4/B08 |
| R978900623 | 4WEH10J4X/6EG24N9ES2K4 |
| R978904564 | 4WEH10J4X/6EG24N9ESK4/B10 |
| R978897583 | 4WEH10J4X/6EG24N9ETK4/10B10 |
| R978901096 | 4WEH10J4X/6EG24N9ETK4/B08 |
| R978906945 | 4WEH10J4X/6EG24N9ETK4/B10V |
| R978909575 | 4WEH10J4X/6EG24N9K4/B08 |
| R978899302 | 4WEH10J4X/6EG24N9K4/V |
| R978896729 | 4WEH10J4X/6EG24N9S2K4 |
| R978897566 | 4WEH10J4X/6EG24N9TK4 |
| R978910974 | 4WEH10J4X/6EG24NESK4/10 |
| R978896905 | 4WEH10J4X/6EG24NETK4/10B10 |
| R978911183 | 4WEH10J4X/6EW110N9ED/B12 |
| R978909383 | 4WEH10J4X/6EW110N9EK4/B08/V |
| R978896775 | 4WEH10J4X/6EW110N9ETK4/B10 |
| R978897221 | 4WEH10J4X/6EW110N9ETK4/B10V |
| R978911249 | 4WEH10J4X/6EW110N9ETK4/B12 |
| R978910685 | 4WEH10J4X/6EW110N9ETK4/V |
| R978908358 | 4WEH10J4X/6EW110N9ETS2K4/B10 |
| R978909410 | 4WEH10J4X/6EW110N9ETSK4/10 |
| R978900644 | 4WEH10J4X/6EW110N9K4 |
| R978909330 | 4WEH10J4X/6EW110N9K4/10 |
| R978914971 | 4WEH10J4X/6EW110N9K4/B10 |
| R978910694 | 4WEH10J4X/6EW110N9K4/V |
| R978897648 | 4WEH10J4X/6EW110N9S2K4 |
| R978908807 | 4WEH10J4X/6EW110NTS2K4 |
| R978905406 | 4WEH10J4X/6EW230N9ETK4/B10 |
| R978910116 | 4WEH10JA4X/6EG24N9TK4 |
| R978899826 | 4WEH10JA4X/6EW110N9ETK4 |
| R978908444 | 4WEH10JA4X/6EW110N9ETK4/B10 |
| R978915902 | 4WEH10JB4X/6EW110N9ETK4/V |
| R978909093 | 4WEH10JB4X/6EW110N9TK4/11 |
| R978912773 | 4WEH10K4X/6EG24N9ETK4 |
| R978916454 | 4WEH10K4X/6EG24N9ETK4/B10 |
| R978912807 | 4WEH10K4X/6EW110N9K4/B10 |
| R978905500 | 4WEH10L4X/6EG24N9ETK4/B10 |
| R978910833 | 4WEH10L4X/6EW110N9ETK4 |
| R978911008 | 4WEH10L4X/6EW110N9ETSK4 |
| R978910226 | 4WEH10M4X/6EG24N9ETK4 |
| R978913411 | 4WEH10M4X/6EG24N9ETK4/10 |
| R978910304 | 4WEH10M4X/6EW110N9ETS2K4 |
| R978910816 | 4WEH10PA4X/6EG24N9TK4 |
| R978906158 | 4WEH10Q4X/6EG24N9ETK4 |
| R978907458 | 4WEH10Q4X/6EG24N9ETSK4/V |
| R978907968 | 4WEH10Q4X/6EW110N9ETK4/B10V |
| R978915758 | 4WEH10Q4X/6EW110N9ETS2K4 |
| R978897650 | 4WEH10Q4X/6EW110N9ETSK4/B10 |
| R978901600 | 4WEH10R4X/6EG24N9EK4 |
| R978906971 | 4WEH10R4X/6EG24N9ETK4/B10 |
| R978912766 | 4WEH10R4X/6EG24NETK4/B08 |
| R978896791 | 4WEH10R4X/6EW110N9ETK4/B10 |
| R978916870 | 4WEH10R4X/6EW110N9K4 |
| R978911009 | 4WEH10R4X/6EW110N9TK4 |
| R978915091 | 4WEH10T4X/6EW110N9ETS2K4 |
| R978910230 | 4WEH10T4X/6EW110N9K4 |
| R978904275 | 4WEH10U4X/6EG24N9ETK4/B10 |
| R978909475 | 4WEH10U4X/6EG24N9ETK4/V |
| R978908578 | 4WEH10U4X/6EG24N9K4/B10 |
| R978909474 | 4WEH10U4X/6EW110N9ETK4 |
| R978914510 | 4WEH10U4X/6EW110N9ETK4/B08 |
| R978911844 | 4WEH10U4X/6EW110N9ETK4/B10 |
| R978909018 | 4WEH10U4X/6EW110N9ETS2K4/V |
| R978911644 | 4WEH10UA4X/6EW110N9K4 |
| R978912210 | 4WEH10UA4X/6EW110N9K4/V |
| R978910714 | 4WEH10UA4X/6EW110NK4 |
| R978910222 | 4WEH10VA4X/6EW110N9K4 |
| R978909352 | 4WEH10W4X/6EG24N9ETS2K4 |
| R978913141 | 4WEH10W4X/6EW110N9EK4 |
| R978914506 | 4WEH10W4X/6EW110N9EK4/B10 |
| R978912412 | 4WEH10W4X/6EW110N9ETK4/B10 |
| R978913783 | 4WEH10W4X/6EW110N9K4 |
| R978911960 | 4WEH10W4X/6EW110N9K4/B08 |
| R978914939 | 4WEH10W4X/6EW110N9K4/B10 |
| R978897424 | 4WEH10Y4X/6EG24N9ETK4/B10V |
| R978896680 | 4WEH10Y4X/6EG24N9K4 |
| R978916001 | 4WEH10Y4X/6EW110N9EK4 |
| R978900497 | 4WEH10Y4X/6EW110N9ETK4 |
| R978912371 | 4WEH10Y4X/6EW110N9ETS2K4/V |
| R900933170 | H-4WEH10C4X/6EG24N9DAL |
| R900771645 | H-4WEH10C4X/6EG24N9EK4/B10 |
| R900932331 | H-4WEH10C4X/6EG24N9ETK4 |
| R900768844 | H-4WEH10C4X/6EG24N9K4 |
| R900929137 | H-4WEH10C4X/6EG24N9S2K4 |
| R900901176 | H-4WEH10C4X/6EG24N9Z45 |
| R900559539 | H-4WEH10C4X/6EW110N9DAL |
| R900745727 | H-4WEH10D42-4X/6EG24NTS2K4/B10D3 |
| R900763165 | H-4WEH10D4X/6EG24N9EK4/B30 |
| R900783366 | H-4WEH10D4X/6EG24N9ETDAL |
| R900760797 | H-4WEH10D4X/6EG24N9ETDK25L/B10D3 |
| R900910502 | H-4WEH10D4X/6EG24N9ETK4/11B25 |
| R900928980 | H-4WEH10D4X/6EG24N9ETK4/B10D3 |
| R900922012 | H-4WEH10D4X/6EG24N9ETK4/D3 |
| R900715331 | H-4WEH10D4X/6EG24N9K4/B08D3 |
| R900705678 | H-4WEH10D4X/6EG24N9K4/B08V |
| R900915219 | H-4WEH10D4X/6EG24N9SK4 |
| R900918434 | H-4WEH10D4X/6EG24N9TDAL |
| R900900738 | H-4WEH10D4X/6EG24N9TDK25L |
| R900731588 | H-4WEH10D4X/6EG24N9TSK4=CSA |
| R900919460 | H-4WEH10D4X/6EG24N9TZ4 |
| R900925754 | H-4WEH10D4X/6EG24NK4 |
| R900927923 | H-4WEH10D4X/6EG96K4 |
| R900915519 | H-4WEH10D4X/6EW110N9Z4/V |
| R900742584 | H-4WEH10D4X/6EW230N9ETK4/B10D3 |
| R900929585 | H-4WEH10D4X/6EW230N9ETS2K4 |
| R900928867 | H-4WEH10D4X/6EW230N9K4 |
| R900917697 | H-4WEH10E4X/6EG24K4 |
| R900933171 | H-4WEH10E4X/6EG24N9DAL |
| R900618055 | H-4WEH10E4X/6EG24N9ETDAL/B10 |
| R900932333 | H-4WEH10E4X/6EG24N9ETK4 |
| R900913343 | H-4WEH10E4X/6EG24N9ETSZ5L |
| R900919030 | H-4WEH10E4X/6EG24N9ETZ4/B10D3 |
| R900709714 | H-4WEH10E4X/6EG24N9S2DAL |
| R900759800 | H-4WEH10E4X/6EG24N9TS2K4 |
| R900715434 | H-4WEH10E4X/6EW110ES2DAL/B10D3 |
| R900617479 | H-4WEH10E4X/6EW110N9ETDAL/B10D3 |
| R900555379 | H-4WEH10E4X/6EW110N9ETZ45/B10D3 |
| R900555921 | H-4WEH10E4X/6EW110N9S2Z4 |
| R900926070 | H-4WEH10EA4X/6EG24K4 |
| R900923683 | H-4WEH10EA4X/6EG24N9K4 |
| R900778572 | H-4WEH10EA4X/6EG24N9K4/B10D3 |
| R900917334 | H-4WEH10EA4X/6EG24N9Z5L/B08 |
| R900727096 | H-4WEH10EA4X/6EW110N9K4 |
| R900733937 | H-4WEH10EA4X/6EW110N9K4/B08D3 |
| R900739563 | H-4WEH10EB4X/6EG24N9ES2K4/B10D3 |
| R900701419 | H-4WEH10EB4X/6EG24N9TK4/B10 |
| R900917417 | H-4WEH10G4X/6EG24N9ES2K4/B10D3 |
| R900906661 | H-4WEH10G4X/6EG24N9ESK4/B10D3 |
| R900919456 | H-4WEH10G4X/6EG24N9ESZ4/B10D3 |
| R900908262 | H-4WEH10G4X/6EG24N9ETK4/B10 |
| R900774748 | H-4WEH10G4X/6EG24N9ETSK4/B10D3 |
| R900932057 | H-4WEH10G4X/6EG24N9K4 |
| R900716177 | H-4WEH10G4X/6EG24N9S2DAL |
| R900913200 | H-4WEH10G4X/6EG24N9S2Z4 |
| R900248770 | H-4WEH10G4X/6EG24NTS2K4 |
| R900577400 | H-4WEH10G4X/6EW110N9S2DAL |
| R900931902 | H-4WEH10GA4X/6EG24N9K4 |
| R900919028 | H-4WEH10H4X/6EG24N9ETS2Z4/B10 |
| R900755430 | H-4WEH10H4X/6EG24N9K4/B10D3 |
| R900608680 | H-4WEH10H4X/6EG24N9SK4 |
| R900918442 | H-4WEH10H4X/6EG24N9TS2Z4/B10 |
| R900727509 | H-4WEH10H4X/6EG24N9TSK4/B10D3V |
| R900700690 | H-4WEH10H4X/6EG96N9SK4 |
| R900555380 | H-4WEH10HC4X/6EW110N9ETZ45/B10D3 |
| R900903281 | H-4WEH10HC4X/O6EW220N9ETZ4/B10D3 |
| R900910876 | H-4WEH10HD4X/6EG24N9ETS2Z4/12B10D3 |
| R900921066 | H-4WEH10HD4X/6EG24N9Z4/10B10D3 |
| R900579583 | H-4WEH10HD4X/OF6EW230NETK4 |
| R900716007 | H-4WEH10J4X/6EG12N9ETS2K4/B10D3V=CSA |
| R900929944 | H-4WEH10J4X/6EG24N9ES2K4 |
| R900903254 | H-4WEH10J4X/6EG24N9ES2Z55L/B10D3V |
| R900918448 | H-4WEH10J4X/6EG24N9ES2Z55L/V |
| R900783365 | H-4WEH10J4X/6EG24N9ETDAL |
| R978901073 | H-4WEH10J4X/6EG24N9ETK4 |
| R900932597 | H-4WEH10J4X/6EG24N9ETK4 |
| R900725075 | H-4WEH10J4X/6EG24N9ETK4/B10D3 |
| R900767323 | H-4WEH10J4X/6EG24N9ETS2K4/B10D3 |
| R900741202 | H-4WEH10J4X/6EG24N9ETSK4/B10D3=CSA |
| R900245872 | H-4WEH10J4X/6EG24N9K4 |
| R900742655 | H-4WEH10J4X/6EG24N9K4=CSA |
| R900755976 | H-4WEH10J4X/6EG24N9TK4/B10V |
| R900919651 | H-4WEH10J4X/6EG24N9TS2Z4 |
| R900768836 | H-4WEH10J4X/6EG24N9TSK4=CSA |
| R900915161 | H-4WEH10J4X/6EG24N9TSZ5L |
| R900914097 | H-4WEH10J4X/6EG24N9Z45 |
| R900920706 | H-4WEH10J4X/6EG24NETK4/B15D3 |
| R900923520 | H-4WEH10JA4X/6EG24N9K4=LB |
| R900727822 | H-4WEH10JB4X/6EW110N9ETK4/B10D3 |
| R900771972 | H-4WEH10L4X/6EG24N9ETK4/10B15=CSA |
| R900770665 | H-4WEH10L4X/6EG24N9ETK4/10B15D3=CSA |
| R900716390 | H-4WEH10L4X/6EG24N9S2K4 |
| R900914096 | H-4WEH10L4X/6EG24N9Z45 |
| R900784214 | H-4WEH10R4X/6EG24N9ETS2K4/B10D3 |
| R900783367 | H-4WEH10U4X/6EG24N9ETDAL |
| R900923928 | H-4WEH10U4X/6EG24N9TK4 |
| R900902931 | H-4WEH10U4X/6EG24N9TZ45 |
| R900751037 | H-4WEH10V4X/6EG24N9ETK4/B06 |
| R900742971 | H-4WEH10V4X/6EG24N9ETK4/B06D3 |
| R900902214 | H-4WEH10X80-4X/6EG24N9ETK4/11B25 |
| R900925162 | H-4WEH10Y4X/6EW110N9SK4 |
4WE 4WE6 24V Hydraulic Directional Control Valve R900561274 4WE6D62/EG24N9K4 4WE6D70/HG24N9K4
R901391204 4WE 10 Y11-5X/HG24N9K4/M
R901391202 4WE 10 Y5X/HG24N9K4/M
R901391202 4WE 10 Y5X/HG24N9K4/M
R900561272 4WE 6 C6X/EG24N9K4
R900561272 4WE 6 C6X/EG24N9K4
R901089245 4WE 6 C7X/HG24N9K4
R901089245 4WE 6 C7X/HG24N9K4
R900574632 4WE 6 D6X/EG24K4QMBG24
R900574632 4WE 6 D6X/EG24K4QMBG24
R900561274 4WE 6 D6X/EG24N9K4
R900561274 4WE 6 D6X/EG24N9K4
R900909559 4WE 6 D6X/EW230N9K4
R900917825 4WE 6 D6X/EW230N9K4/V
R901087088 4WE 6 D7X/HG24N9K4
R901087088 4WE 6 D7X/HG24N9K4
R900561278 4WE 6 E6X/EG24N9K4
R900561278 4WE 6 E6X/EG24N9K4
R900912492 4WE 6 E6X/EW230N9K4
R901087087 4WE 6 E7X/HG24N9K4
R901087087 4WE 6 E7X/HG24N9K4
R900561280 4WE 6 EA6X/EG24N9K4
R901108712 4WE 6 EA7X/HG24N9K4
R901108712 4WE 6 EA7X/HG24N9K4
R900933648 4WE 6 F6X/EG24N9K4
R900561282 4WE 6 G6X/EG24N9K4
R900561282 4WE 6 G6X/EG24N9K4
R900561286 4WE 6 H6X/EG24N9K4
R900561286 4WE 6 H6X/EG24N9K4
R900561288 4WE 6 J6X/EG24N9K4
R900561288 4WE 6 J6X/EG24N9K4
R901089241 4WE 6 J7X/HG24N9K4
R901089241 4WE 6 J7X/HG24N9K4
R901108702 4WE 6 JA7X/HG24N9K4
R900901751 4WE 6 L62/EG24N9K4
R900901751 4WE 6 L6X/EG24N9K4
R900577475 4WE 6 M6X/EG24N9K4
R900577475 4WE 6 M6X/EG24N9K4
R900572785 4WE 6 U6X/EG24N9K4
R900940418 4WE 6 Y11-6X/EG24N9K4
R900561276 4WE 6 Y6X/EG24N9K4
R900561276 4WE 6 Y6X/EG24N9K4
R901089243 4WE 6 Y7X/HG24N9K4
R901089243 4WE 6 Y7X/HG24N9K4
R900593277 4WE10 C3X/CG24N9K4
R900588201 4WE10 E3X/CG24N9K4
R900594277 4WE10 G3X/CG24N9K4
R900597986 4WE10 H3X/CG24N9K4
R900707281 4WE10 M3X/CG24N9K4
R900595531 4WE10 Y3X/CG24N9K4
R900912496 4WE10D3X/CW230N9K4
R901278763 4WE10D5X/OFEG24N9K4/M
R900911869 4WE10E3X/CW230N9K4
R901278762 4WE10H5X/EG24N9K4/M
R900911868 4WE10J3X/CW230N9K4
R900909559 4WE6D6X/EW230N9K4
R900912492 4WE6E6X/EW230N9K4
R901432612 4WE 10 D5X/HG24N9K4QYBG24/M
R901278761 4WE 10 E5X/EG24N9K4/M
R901390857 4WE 10 E5X/HG24N9K4/M
R901390857 4WE 10 E5X/HG24N9K4/M
R901391198 4WE 10 EA5X/HG24N9K4/M
R901391198 4WE 10 EA5X/HG24N9K4/M
R901391199 4WE 10 EB5X/HG24N9K4/M
R901278781 4WE 10 F5X/EG24N9K4/M
R901427832 4WE 10 G5X/HG24N9K24/M
R901427832 4WE 10 G5X/HG24N9K4/M
R900911868 4WE 10 J3X/CW230N9K4
R901278744 4WE 10 J5X/EG24N9K4/M
R901278744 4WE 10 J5X/EG24N9K4/M
R901401552 4WE 10 J5X/HG24N9K4/M
R901401552 4WE 10 J5X/HG24N9K4/M
R901391161 4WE 10 L5X/HG24N9K4/M
R901391161 4WE 10 L5X/HG24N9K4/M
R901391194 4WE 10 U5X/HG24N9K4/M
R901391194 4WE 10 U5X/HG24N9K4/M
|
Charge pump
|
Hydraulic pump parts
|
|
|
Hydraulic pump
|
Cylinder block
|
Press pin
|
|
Piston motor
|
Piston shoe
|
Snap ring
|
|
Piston pump
|
Retainer plate
|
Coil spring
|
|
Gear pump
|
Ball guide
|
Disk spring
|
|
Charge pump
|
Valve plate
|
Barrel washer
|
|
Pilot pump
|
Shoe plate
|
Oil seal
|
|
Vane pump
|
Bearing plate
|
Frication plate
|
|
Repair OEM parts
|
Swash plate
|
Steel plate
|
|
Motor spare parts
|
Drive shaft
|
Metal
|
| Pressure | Standard |
| Structure | Standard |
| Power | Standard |
| Dimension(L*W*H) | 20x10x5 |
| Maximum pressure | Standard |
| Maximum Flow Rate | Standard |
Similar Products
Get in Touch
Have questions about our products or want to discuss a custom order? Our team is ready to help you.
Company
BETTER PARTS Machinery Co., Ltd.
Location
Room 301-2295, Building 6, Kelin Road, Tianhe District, Guangzhou
Contact Person
Bonnie
