Energy Saving Excavator Test Bench Hydraulic Environmental Protection
Excavator hydraulic test benches environmental protection and energy saving
Quick Detail
HIGHLAND hydraulic was founded in 2007, located in Licheng District, Jinan City. The company has long been committed to the R & D and production of multi-functional hydraulic comprehensive test-bed, and has gathered a group of high-quality technical and management talents. It has hydraulic pumps, hydraulic motors, hydraulic systems, hydraulic test-bed testing services, etc. The company has always adhered to the enterprise spirit of "honesty, honesty, diligence, pragmatism, pioneering and innovation", with strong technical force, advanced equipment Standardized management and rigorous scientific attitude serve customers.
Description
Technical parameter
|
Highland Hydraulic Test Benches Machine Technical parameter
|
|
|
Pressure(mpa)
|
35mpa / 42mpa
|
|
Flow rate(L/min)
|
380L/min / 450L/min / 500L/min
|
|
Power(KW)
|
75kw / 90kw / 110kw / 160kw / 200kw / 250kw / 315kw
|
|
Power Drive Mode
|
Electromotor / Diesel engine drive / Hydraulic mortor / Power recovery
|
|
Speed Range
|
1000r/min / 0-1500r/min / 0-2500r/min
|
|
Load location
|
Liquid control loading / Proportional loading
|
|
Show location
|
Locale/ Computer (long-distance)
|
|
Working Medium
|
Hydraulic oil
|
|
Composition
|
Pressure, flow, speed, displacement and volume, open and closed pumps, left and right rotation items, motors, oil cylinders, torque, power, computer generated test reports, graphs, computer collected data, printouts
|
|
Applicable area
|
Apply to performance test of the hydraulic components that supported by a host in engineering machinery, metallurgical, petroleum, machinery, aerospace, shipbuilding and other fields.
|
Hydraulic test standsNotices
Hydraulic Test Benches Main Model
● YST-300 Hydraulic Motor Test Tench
● YST-300 Digit Hydraulic Test Bench
●YST-380 Hydraulic Pump Test Tench
● YST-380 Adjustable Hydraulic Comprehensive Test Bench
● YST-380 Digit Hydraulic Comprehensive Test Bench
● YST-500 Hydraulic Comprehensive Test Bench
Applications
Highland hydraulic focuses on the research and development and application of hydraulic technology, and has accumulated rich experience in the test, detection and maintenance of hydraulic components such as hydraulic pumps, hydraulic motors and hydraulic valves. Highland hydraulic component comprehensive test bench, hydraulic pump test bench, hydraulic motor test bench, hydraulic valve test bench and oil cylinder test bench produced by it are at the domestic level and are widely used in the production and maintenance industry of hydraulic components such as hydraulic pumps, hydraulic equipment and construction machinery, The company has customers all over the world and Southeast Asia, and has been widely praised by customers.
