Automatic Pharmaceutical Cosmetic Glass Ampoule Washing Filling Sealing Machine For Liquid
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
Negotiable
Brand:
Huiheng
Product Description
Pharmaceutical Cosmetic Automatic Glass Ampoule Liquid Washing Filling and Sealing Machine
Main application:
The linkage line consists of HQCLA series vertical ultrasonic washing machine, HSDH series hot air circulation sterilization tunnel, HSFG series filling and stoppering machine. The model can be used in combination or in a single machine. The linkage line can complete water spray filling, ultrasonic cleaning and flushing (internal and external), CA flushing (internal and external), preheating, drying and sterilizing to remove heat source, cooling, filling, sealing, capping and other processes etc.This line can meet the size ranging from 2-30ml vials of washing, drying and sterilizing to remove heat source, filling and sealing requirements of the production process.
| Model | SHH-2 | SHH-4 | SHH-6 | SHH-8 | SHH-10 | SHH-12 | SHH-16 | SHH-20 |
| Suitable size | 2-30ML(VIAL | |||||||
| Output(pcs/min) | 20-60 | 40-120 | 60-200 | 100-250 | 120-300 | 150-400 | 200-500 | 280-600 |
| Filling heads | 2 | 4 | 6 | 8 | 10 | 12 | 16 | 20 |
| Power supply | 380vV 50HZ | |||||||
| Power capacity(KW) | 79 | 79 | 90 | 92 | 108 | 108 | 115 | 132 |
| Total weight(KG) | 8500 | 8500 | 8800 | 9300 | 9900 | 10200 | 10800 | 11800 |
| Overall diemension(mm) | 9050*2200*2450 | 9050*2200*2450 | 9700*2200*2450 | 9700*2200*2450 | 10850*2200*2450 | 10850*2200*2450 | 117700*2200*2450 | 13653*2200*2450 |
