Automatic Vial Bottle Washing Drying Filling Stoppering Capping Production Line for Powder
Main description:
The core design of the powder filling machine is to use the combination of servo motor and updated auger, which ensures the accuracy of the filling dosage. With the exact amount of powder filled in, rubber stopper will then be automatically sealed on top of each vial.
Main features:
1. Low speed rotary powder filling machine GTI-B2-dual intermittent feeding, filling and stoppering
2. High speed rotary powder filling machine GTI-P4- Continuous feeding, stoppering; intermittent filling. Automate rejecting and sampling. No vial no filling; no vial no stoppering.
3. Linear powder filling machine GTI-Z2- Dual continuous feeding, stoppering; intermittent filling. Automate rejecting and sampling. No vial no filling; no vial no stoppering.
4. Powder filling screw capping machine GTI-X2- Dual intermittent feeding, filling and screw capping
Technical parameters:
| Description |
Low speed rotary powder filling machine |
High speed rotary powder filling machine |
Linear powder filling machine |
Powder filling screw capping machine |
| Model | SHH-B2 | SHH-P4 | SHH-Z2 | SHH-X2 |
| 7ML | 7200 | 22000 | 15000 | 6000 |
| 10ML | 7200 | 22000 | 15000 | 6000 |
| 15ML | 6000 | 19000 | 12000 | 5400 |
| 20ML | 5600 | 16800 | 12000 | 5400 |
| 25ML | 4900 | 15000 | 10000 | 4800 |
| 30ML | 4800 | 12000 | 10000 | 4800 |
| Power supply | 380V/50Hz/3Phases | |||
| Vacuum | -0.066MPa, 8m³/h | -0.066MPa, 14m³/h | -0.066Pa, 10m³/h |
-0.066Pa, 8m³/h |
|
Power |
1KW | 6KW | 3KW | 3KW |
|
Noise Level |
≤65db |
≤65db |
≤65db |
≤65db |
|
Max Capacity |
7200 | 22000 | 15000 | 6000 |
|
Tolerance |
≤±2% |
≤±2% |
≤±2% |
≤±2% |
|
Completion rate |
99.5% |
99.5% |
99.5% |
99.5% |
|
Dimension |
1800*940*1800 |
3240*1100*1800 |
2330*1320*1800 |
1955*1188*1800 |
| Feeding height | 900±20mm | 900±20mm | 900±20mm | 900±20mm |
| Weiight | 860KG | 1400KG | 1100KG | 1000KG |
Details Picture:
