GMP Pharma Automatic Injection Liquid Glass Vial Filling and Capping Machine Line
GMP Pharma Automatic Injection Liquid Glass Vial Filling and Capping Machine Line
Products Description:
GMP Pharma Automatic Injection Liquid Glass Vial Filling and Sealing Machine Line is suitable for pharmaceutical enterprise or laboratory small-batch production.
This machine adopts mechanical and electrical integration automatic controlling, plunger pump ( or peristaltic pump ) for filling.
It is easy to change standard components. Laminal flow system and stopper feeding system meet new GMP requirements.
Features:
* Peristaltic pump or high precision peristaltic pump filling, filling speed is high and filling error is small.
* Groove cam device positions bottles precisely. Running is stable, change part is east to change.
* Button control panel is easy to operate and it has high automation degree.
* Falling bottle auto rejected in the turntable, no bottle, no filling; machine auto stops when no stopper; auto alarms when insufficient stopper
* Equip with auto counting function.
* Certified, standard electric installation, safety guarantee on operation.
* Optional acrylic glass protection hood and 100-class laminar flow.
* Optional pre-filling and after-filling nitrogen filling.
* The whole machine is designed according to GMP requirements.
Technical Data:
| Product Name | GMP Pharma Automatic Injection Liquid Glass Vial Filling and Sealing Machine |
| Suitable bottle range | 2~250ml glass or plastic bottles (change the proper change part) |
| Production capacity | 7ml vial, Dosage1ml, 100-120bts/min |
| Filling error | ≤1.5% |
| Auto stoppering ratio | ≥99% |
| Power supply | 220V/380V 50Hz |
| Power | 1 kw |
| Vacuum degree | -6×10-2Mpa 14m3/h |
| Single machine noise | ≤70dB |
| Weight | 400Kg |
| Dimension | 1680×1000×1750(mm) |
Details:
