Raised Face Weld Neck Pipe Flanges Class150 300LB ASME B16.5 Forged
ASME B16.5 Forged Welding Neck Flange Class150 WN Raised Face Weld Neck Flange
If the pressure and sealing requirements are not strict, the flat welding flange is a good choice. Welded neck flange refers to a flange with a tapered neck and butt welding with the cylinder of pipe.The strength and rigidity of the flange are strengthened, and the sealing performance is better than that of the flat welding flange. WN flange is short for Weld Neck Flange. It is an integral flange. The disadvantage is that it needs to be manufactured with forgings, which consumes a lot of materials and costs a lot.
It is suitable for occasions with high pressure or high sealing requirements.
| Product Name | ASME B16.5 Forged Welding Neck Flange Class150 WN Raised Face Weld Neck Flange | |
| Types | Welding Neck | |
| Face Finish | RF,FF | |
| Standard | ANSI | ANSI B16.5 ASME B16.47 series A/B |
| DIN | DIN 2631 2573 2527 2565 2641 | |
| EN | EN1092-1:2002 | |
| SABS | SABS 1123 | |
| Material | ANSI | CS A105/SA 105N,SS 304/304L,316/316L Alloy Steel: WHPY45/52/65/80 |
| DIN | CS RST37.2;S235JR SS 304/304L,316/316L | |
| GOST | CS CT20;16MN;SS 304/304L,316/316L | |
| EN | CS RST37.2;S235JR;C22.8SS 304/304L,316/316L | |
| SABS | CSRST37.2;S235JR;Q235;SS 304/304L,316/316L | |
| Pressure | ANSI | Class 150, 300, 600, 900, 1500 2500lbs |
| DIN | PN6,PN10,PN16,PN25,PN40,PN64,PN100 | |
| EN | PN6,PN10,PN16,PN25,PN40,PN64,PN100 | |
| JIS | 1K,2K,5K,10K,16K,20K,30K,40K | |
| Size | ANSI | 1/2” – 60” |
| Coating | black paint, anti-rust oil, galvanizing etc | |
| Usage | pipeline. to convey the water, steam, air, gas and oil | |
| Certificate | CE, iso | |
| Delivery | According to the quantity | |
