6m Length 304 Stainless Steel Angle Bar Hot Rolled Equal Channel Bar
Price:
1.91
MOQ:
30
Delivery Time:
Negotiable
Product Description
6m Length 304 Stainless Steel Angles Equal Stainless Steel Bar
High-quality stainless steel angle and channel bars available in various grades and sizes for industrial applications.
Product Specifications
General Specifications
| Product Name | Stainless Steel Angle Bar / Stainless Steel Channel Bar |
|---|---|
| Available Grades | 201, 304, 310S, 316L, 321, 2205, etc. |
| Standards | ASTM, GB, DIN |
| Angle Bar Size Range | 30×30×3 - 200×200×10mm × 6m length |
| Channel Bar Size Range | 50×30×3 - 200×100×10mm × 6m length |
| Services | Cutting |
| Packing | Waterproof paper surround or wooden pallets |
| Brand | TSINGSHAN |
Stainless Steel Angle Bar - Standard Sizes & Weight per Meter
| Size (A×B mm) | 3mm | 4mm | 5mm | 6mm | 7mm | 8mm | 9mm | 10mm |
|---|---|---|---|---|---|---|---|---|
| 20×20 | 0.894 | 1.13 | 1.38 | |||||
| 25×25 | 1.13 | 1.45 | 1.77 | 2.06 | ||||
| 30×30 | 1.37 | 1.77 | 2.17 | 2.53 | ||||
| 35×35 | 1.61 | 2.09 | 2.57 | 3.01 | ||||
| 40×40 | 1.85 | 2.41 | 2.97 | 3.49 | ||||
| 45×45 | 2.12 | 2.76 | 3.40 | 4.00 | ||||
| 50×50 | 2.36 | 3.07 | 3.79 | 4.46 | 5.13 | 5.76 | 6.42 | 7.06 |
| 60×60 | 4.58 | 5.42 | 6.24 | 7.03 | ||||
| 63×63 | 5.03 | 5.95 | 6.84 | 7.71 | 8.60 | 9.48 | ||
| 70×70 | 5.42 | 6.42 | 7.39 | 8.34 | 9.31 | 10.3 | ||
| 75×75 | 5.82 | 6.89 | 7.95 | 8.97 | 10.0 | 11.1 | ||
| 80×80 | 7.37 | 8.50 | 9.61 | 10.7 | 11.8 | |||
| 90×90 | 8.33 | 9.65 | 11.90 | 12.2 | 13.4 | |||
| 100×100 | 9.28 | 10.8 | 12.20 | 13.6 | 15.0 |
Stainless Steel Channel Bar - Standard Sizes & Weight per Meter
| Size (H×B mm) | 3mm | 4mm | 5mm | 6mm | 7mm | 8mm | 9mm | 10mm | 12mm |
|---|---|---|---|---|---|---|---|---|---|
| 40×20 | 1.79 | ||||||||
| 50×25 | 2.27 | ||||||||
| 60×30 | 2.74 | 3.56 | 4.37 | 5.12 | |||||
| 70×35 | 3.23 | 4.21 | 5.17 | 6.08 | |||||
| 80×40 | 3.71 | 4.84 | 5.96 | 7.03 | |||||
| 90×45 | 4.25 | 5.55 | 6.83 | 8.05 | |||||
| 100×50 | 4.73 | 6.18 | 7.62 | 8.98 | 10.3 | 11.7 | 13.0 | 41.2 | |
| 120×60 | 9.20 | 10.9 | 12.6 | 14.2 | |||||
| 130×65 | 10.1 | 11.9 | 13.8 | 15.5 | 17.3 | 19.1 | |||
| 140×70 | 12.9 | 14.9 | 16.8 | 18.8 | 20.7 | ||||
| 150×75 | 13.9 | 16.0 | 18.1 | 20.2 | 22.2 | 26.3 | |||
| 160×80 | 14.8 | 17.1 | 19.3 | 21.6 | 23.8 | 28.1 | |||
| 180×90 | 16.7 | 19.4 | 22.0 | 24.5 | 27.0 | 32.0 | |||
| 200×100 | 18.6 | 21.6 | 24.5 | 27.4 | 30.2 | 35.8 |
About Our Company
Our company is a comprehensive stainless steel enterprise specializing in material wholesale, processing, storage, and distribution. Located in Wuxi - the stainless steel trading center, we have a total investment of 10 million yuan with annual sales exceeding 300 million yuan.
Material Range & Processing Capabilities
- Materials: 310S, 309S, 316L, 321, 304L, TP304, 347H, 17-4PH, 317L, 2507, 2205-904L and other specialized alloys
- High-temperature resistant stainless steel series, duplex stainless steel series, and super stainless steel series
- Processing equipment: Plasma cutting machines, coil material opening equipment, laser cutting machines
- Surface finishing: 8K mirror polishing, grinding, wire drawing, film and titanium plating
- Specialized services: Thick plate cutting (up to 150mm), custom shapes, casting and forging parts
We maintain long-term partnerships with major steel mills including Taiyuan, East, Zhang Pu, Hongxing, Zhejiang Qingshan, and source imported stainless steel plates from Sweden, North America, South Africa, Japan, and Korea.
Our materials are widely used in machinery, chemical, petroleum, boiler, heat exchanger, food machinery, beverage machinery, medical equipment, and various other industries.
Product Gallery
Applications
Stainless steel angle bars and channel bars are primarily used for constructing frame structures in various industries:
- High-voltage power transmission towers
- Steel structure bridge frameworks
- Tower crane columns and booms on construction sites
- Workshop columns and beams
- Air-conditioning and solar panel mounting brackets
- Building structures and engineering construction
- Ship beams and industrial furnaces
Our stainless steel angle bars and channel bars are applied across diverse industrial sectors including construction, marine, energy, and manufacturing industries.
Contact Information
For inquiries about our stainless steel angle bars and channel bars, please contact our sales team for pricing, specifications, and delivery information.
