500T Crimping Force AC Hose Crimper with 14-87mm Range and 3KW Power for Hydraulic Hose Assembly
Price:
Contact Us
MOQ:
1 Set
Delivery Time:
2 - 7 Working Days
Brand:
MENSION
Product Description
Machinery Repair AC Cable Crimping Machine Rubber Hose Assembly Fabricating
REPAIR AC HOSE CRIMPING MACHINE MS-51CG
DESCRIPTION
MS-51CG air conditioner hose crimper machine is famous for its large productivity. It is capable of crimping high pressure hydraulic oil hose on construction and engineering machine, and also swaging the metal tube size, pressing the wire ropes for safety use.
MAIN ADVANTAGES
- One piece design cylinder head, prevent pressure lose
- Foot pedal makes the crimping work more flexible
- Working lamp, improve the safety level
- Die sets with high temperature heat processing, high hardness
- Simple structure and design, easy maintenance and low cost
TECHNICAL DATA
| Model | MS-51CG AC Hose Crimping Machine |
|---|---|
| Crimping Range | 14 - 87 (mm) |
| Crimping Force | 500 (T) |
| Hose Size | 1/4 - 2 (inch) |
| Max. Opening | 30 (mm) |
| Die Sets | 10 |
| Die Set Type | 51 |
| System Pressure | 31.5 (Mpa) |
| Accuracy | 0.05 (mm) |
| Control | MS |
| Standard Voltage | 220 (V) / 380 (V) |
| Motor Power | 3 (KW) |
| Length | 800 (mm) |
| Width | 640 (mm) |
| Height | 1300 (mm) |
| Weight | 320 (KG) |
51 SERIES HOSE CRIMPER DIE SETS
| Die No. | Crimping Range | Length |
|---|---|---|
| 6* | 6 - 8 mm | 35 |
| 8* | 8 - 10 mm | 35 |
| 10* | 10 - 12 mm | 35 |
| 12* | 12 - 15 mm | 35 |
| 15 | 15 - 19 mm | 60 |
| 19 | 19 - 23 mm | 60 |
| 23 | 23 - 26 mm | 60 |
| 26 | 26 - 31 mm | 60 |
| 31 | 31 - 36 mm | 70 |
| 36 | 36 - 41 mm | 70 |
| 41 | 41 - 47 mm | 70 |
| 47 | 47 - 55 mm | 80 |
| 55 | 55 - 63 mm | 80 |
| 63 | 63 - 69 mm | 80 |
| 69* | 69 - 76 mm | 100 |
NOTE
- * for non standard die sets
- Customized die sets are available
- Special voltage 110V, 208V, 240V, 415V are available
OPTIONAL
- Quick Change Tool
- UC control
Forged from top-grade materials
Oil detection system
High-quality high-strength molds
Convenient operation panel
High-quality crimping effect
