780T Hydraulic Hose Crimper with 14-127mm Crimping Range and 15 Die Sets for AC Hose Crimping Machine
Price:
Contact Us
MOQ:
1 Set
Delivery Time:
2 - 7 Working Days
Brand:
MENSION
Product Description
Automotive AC Hose Crimper Used Hydraulic Crimping Machine For Sale
AC HYDRAULIC HOSE CRIMPING MACHINE MS-E150
MS-E150 AC hydraulic hose crimper machine is renowned for its extensive crimping range. This reliable and accurate machine offers exceptional stability for industrial applications.
MAIN FEATURES
- Die sets choosing reference sheet for new users
- Die sets with high hardness for durability
- Hydraulic oil cylinder designed for easy maintenance
- Diameter control ruler with high precision accuracy
TECHNICAL DATA
| Model | MS-E150 AC Hose Crimping Machine |
|---|---|
| Crimping Range | 14 - 127 (mm) |
| Crimping Force | 780 (T) |
| Hose Size | 1/4 - 3 (inch) |
| Max. Opening | 35 (mm) |
| Die Sets | 15 |
| Die Set Type | 150 |
| System Pressure | 31.5 (Mpa) |
| Accuracy | 0.01 (mm) |
| Control | MS |
| Standard Voltage | 220 (V) / 380 (V) |
| Motor Power | 3 (KW) |
| Length | 650 (mm) |
| Width | 550 (mm) |
| Height | 650 (mm) |
| Weight | 250 (KG) |
150 HOSE CRIMPER DIE SETS
| Die No. | Crimping Range | Length |
|---|---|---|
| 6* | 6 - 8 mm | 55 |
| 8* | 8 - 10 mm | 55 |
| 10* | 10 - 12 mm | 55 |
| 12* | 12 - 14 mm | 55 |
| 14 | 14 - 16 mm | 55 |
| 16 | 16 - 19 mm | 55 |
| 19 | 19 - 22 mm | 55 |
| 22 | 22 - 26 mm | 70 |
| 26 | 26 - 30 mm | 70 |
| 30 | 30 - 34 mm | 70 |
| 34 | 34 - 39 mm | 75 |
| 39 | 39 - 45 mm | 75 |
| 45 | 45 - 51 mm | 90 |
| 51 | 51 - 57 mm | 90 |
| 57 | 57 - 63 mm | 100 |
| 63 | 63 - 69 mm | 110 |
| 69 | 69 - 74 mm | 110 |
| 74 | 74 - 78 mm | 110 |
| 78 | 78 - 87 mm | 110 |
Additional Options & Notes:
1) Customized die sets are available with different sizes or shapes
2) Special voltages including 110V, 208V, 240V, and 415V are available
3) Foot pedal accessory available for hands-free operation
4) * indicates non-standard die sets
1) Customized die sets are available with different sizes or shapes
2) Special voltages including 110V, 208V, 240V, and 415V are available
3) Foot pedal accessory available for hands-free operation
4) * indicates non-standard die sets
