High Pressure Hydraulic Hose Crimper Air Conditioning Hose Crimping Tool Water Line Crimper
Price:
Contact Us
MOQ:
1 Set
Delivery Time:
2 - 7 Working Days
Brand:
MENSION
Product Description
MS-51M Manual High Pressure Hose Crimper
Product Overview
The MS-51M manual hose crimping machine is specifically engineered for on-site crimping applications where electrical power is unavailable. Equipped with a high-capacity hydraulic manual pump, this tool can crimp hydraulic high pressure hoses up to 2 inches for 4SH and 4SP specifications.
Key Advantages
- Compact structure for easy transportation and mobility
- High precision dial for enhanced operational convenience
- Hard polishing molds with superior hardness and durability
- Secure die sets box for safe storage and organization
Technical Specifications
| Model | MS-51M Manual Hose Crimping Machine |
|---|---|
| Crimping Range | 14 - 87 (mm) |
| Crimping Force | 350 (T) |
| Hose Size | 1/4 - 2 (inch) |
| Max. Opening | 31 (mm) |
| Die Sets | 10 |
| Die Set Type | 51 |
| System Pressure | 31.5 (Mpa) |
| Accuracy | 0.01 (mm) |
| Control | MS |
| Standard Voltage | Manual Pump |
| Motor Power | Manual Pump |
| Length | 730 (mm) |
| Width | 550 (mm) |
| Height | 680 (mm) |
| Weight | 170 (KG) |
Important Notes: Customized die sets are available upon request. Maximum opening refers to the stroke measurement between fully closed and fully opened die sets.
Optional Accessories
- Quick Change Tool
- Quick Change Die Set Rack
- UC Control System
Standard Die Sets Configuration
| Die Number | Crimping Range |
|---|---|
| 6* | 6 - 8mm |
| 8* | 8 - 10mm |
| 10* | 10 - 12mm |
| 12* | 12 - 14mm |
| 14 | 14 - 16mm |
| 16 | 16 - 19mm |
| 19 | 19 - 23mm |
| 23 | 23 - 27mm |
| 27 | 27 - 31mm |
| 31 | 31 - 35mm |
| 35 | 35 - 41mm |
