DX68 High Hardness 12V Hydraulic Hose Crimping Machine Air Hose Crimper

Price Negotiable

Price: Contact Us

MOQ: 1 Set

Delivery Time: 2 - 7 Working Days

Brand: MENSION

Product Description

DX68 High Hardness 12V Hydraulic Hose Crimping Machine

12V Hose Crimper Machine - Model MS-51DC

The MS-51DC is a unique DX68 hose crimping machine that utilizes a car battery as its drive power source. With ten die sets included, this machine can crimp hoses ranging from 1/4 inch to 2 inches, and can handle industrial hoses up to 3 inches.

Main Features

Forged hydraulic oil cylinder with high hardness construction
Easy hand-held operation panel for enhanced convenience
Precise crimping diameter control ruler
Advanced back mechanical positioning device

Technical Specifications

Model	MS-51DC Hose Crimping Machine
Crimping Range	14 - 87 mm
Crimping Force	300 T
Hose Size	1/4 - 2 inch
Max. Opening	30 mm
Die Sets	10
Die Set Type	51
System Pressure	31.5 Mpa
Accuracy	0.05 mm
Control	MS
Standard Voltage	220 V / 380 V
Motor Power	3 KW
Length	650 mm
Width	600 mm
Height	600 mm
Weight	170 KG

MS-51DC Hose Crimping Machine - Front view showing control panel and crimping mechanism

51 Hose Crimper Die Sets

Die No.	Crimping Range (mm)	Length (mm)
6*	6.0 - 8.0	35
8*	8.0 - 10.0	35
10*	10.0 - 12.0	35
12*	12.0 - 15.0	35
15	15.0 - 19.0	60
19	19.0 - 23.0	60
23	23.0 - 26.0	60
26	26.0 - 31.0	60
31	31.0 - 36.0	70
36	36.0 - 41.0	70
41	41.0 - 47.0	70
47	47.0 - 55.0	80
55	55.0 - 63.0	80
63	63.0 - 69.0	80
69*	69.0 - 76.0	90
