Workshop Used Hydraulic Hose Crimper with 300T Crimping Force and 14-87mm Crimping Range
Price:
Contact Us
MOQ:
1 Set
Delivery Time:
2 - 7 Working Days
Brand:
MENSION
Product Description
Workshop Used Hose Crimping Machine Synflex Hydraulic Hose Crimper
HYDRAULIC HOSE CRIMPING MACHINE 51DC
DESCRIPTION
New type MS-51DC hose crimping machine is designed for hydraulic high pressure stainless steel braided rubber hose crimping. It features light weight and compact dimensions for workshop efficiency.
MAIN FEATURES
- Convenient die sets installation
- One piece forged hydraulic cylinder
- High precision micrometer
- Pedal press operation for enhanced convenience
TECHNICAL DATA
| Model | MS-51DC Hydraulic Hose Crimper Machine |
|---|---|
| Crimping Range | 14 - 87 (mm) |
| Crimping Force | 300 (T) |
| Hose Size | 1/4 - 2 (inch) |
| Max. Opening | 30 (mm) |
| Die Sets | 10 |
| Die Set Type | 51 |
| System Pressure | 31.5 (Mpa) |
| Accuracy | 0.05 (mm) |
| Control | MS |
| Standard Voltage | 220 (V) / 380 (V) |
| Motor Power | 3 (KW) |
| Length | 650 (mm) |
| Width | 600 (mm) |
| Height | 600 (mm) |
| Weight | 170 (KG) |
51 CRIMPER DIE SETS
| Die No. | Crimping (mm) | Length (mm) |
|---|---|---|
| 6* | 6.0 - 8.0 | 35 |
| 8* | 8.0 - 10.0 | 35 |
| 10* | 10.0 - 12.0 | 35 |
| 12* | 12.0 - 15.0 | 35 |
| 15 | 15.0 - 19.0 | 60 |
| 19 | 19.0 - 23.0 | 60 |
| 23 | 23.0 - 26.0 | 60 |
| 26 | 26.0 - 31.0 | 60 |
| 31 | 31.0 - 36.0 | 70 |
| 36 | 36.0 - 41.0 | 70 |
| 41 | 41.0 - 47.0 | 70 |
| 47 | 47.0 - 55.0 | 80 |
| 55 | 55.0 - 63.0 | 80 |
| 63 | 63.0 - 69.0 | 80 |
| 69* | 69.0 - 76.0 | 90 |
NOTE
- " * " indicates non-standard die sets
- Customized die sets are available upon request
- Available AC voltages: 110V, 208V, 220V, 240V, 380V, 415V
