Manual Brake Hose Crimping Machine with 200T Crimping Force, 12 Die Sets, and Portable Manual Pump
Price:
Contact Us
MOQ:
1 Set
Delivery Time:
2 - 7 Working Days
Brand:
MENSION
Product Description
Finn Power Crimper Manual Brake Hose Crimping Machine
MS-P20HP Brake Hose Crimping Machine
MS-P20HP is a manual portable hose crimping machine designed for on-site crimping of high-pressure oil hoses, pipes, and cables. It features a high-quality hand pump with an easy pressure release device.
Key Advantages
- Movable with light weight and compact size
- High crimping force capability
- Ergonomic die sets with high hardness
- High precision micrometer for accurate measurements
Technical Specifications
| Model | P20HP Brake Hose Crimper |
| Crimping Range | 12 - 57 mm |
| Crimping Force | 200 T |
| Hose Size | 1/4 - 1 1/4 inch |
| Max. Opening | 28 mm |
| Die Sets | 12 |
| Die Set Type | P20 |
| System Pressure | 31.5 MPa |
| Accuracy | 0.01 mm |
| Control | MS |
| Standard Voltage | Manual Pump |
| Motor Power | Manual Pump |
| Length | 550 mm |
| Width | 520 mm |
| Height | 400 mm |
| Weight | 70 KG |
P20 Hose Crimper Die Sets
| Die No. | Crimping Range | Length |
|---|---|---|
| 6* | 6 - 8mm | 55 |
| 8* | 8 - 10mm | 55 |
| 10* | 10 - 12mm | 55 |
| 12 | 12 - 15mm | 55 |
| 15 | 15 - 18mm | 55 |
| 18 | 18 - 21mm | 55 |
| 21 | 21 - 24mm | 55 |
| 24 | 24 - 27mm | 55 |
| 27 | 27 - 30mm | 70 |
| 30 | 30 - 36mm | 70 |
| 33 | 33 - 36mm | 70 |
| 36 | 36 - 39mm | 75 |
| 39 | 39 - 45mm | 75 |
| 45 | 45 - 48mm | 75 |
| 48 | 48 - 57mm | 90 |
* Denotes non-standard die sets
Customized die sets are available upon request
Maximum opening refers to the stroke between die sets fully closed and fully opened
Optional Accessories
- Quick Change Tool
- Quick Change Die Set Rack
- UC Control System
