Portable Hydraulic Hose Crimping Machine with 380T Crimping Force and 14 Die Sets for Efficient Hose Fitting

Price Negotiable

Price: Contact Us

MOQ: 1 Set

Delivery Time: 2 - 7 Working Days

Brand: MENSION

Product Description

Portable Hydraulic Hose Crimping Machine Brass Ferrule Crimper Hose Fitting Crimping Tool

2.5 Inch Portable Hydraulic Hose Crimper MS-P150

Description

MS-P150 portable hydraulic hose crimping machine can be used easily for big bend fittings. The crimping unit is separated with the hydraulic drive unit, making crimping operations more convenient.

Advantages

High quality mold steel Cr12Mov die sets with high hardness
Quick die sets change and installation
Advanced touchscreen operation for increased intelligence

Technical Data

Model	MS-P150 Portable Hydraulic Hose Crimper
Crimping Range	14 - 87 (mm)
Crimping Force	380 (T)
Hose Size	1/4 - 2 1/2 (inch)
Max. Opening	61 (mm)
Die Sets	14
Die Set Type	P150
System Pressure	31.5 (Mpa)
Accuracy	0.01 (mm)
Control	UC
Standard Voltage	220 (V) / 380 (V)
Motor Power	3.75 (KW)
Length	720 (mm)
Width	970 (mm)
Height	1600 (mm)
Weight	1020 (KG)

MS-P150 Portable Hydraulic Hose Crimping Machine

P150 Series Crimper Die Sets

Die No.	Crimping Range	Length
6*	6 - 8mm	55
8*	8 - 10mm	55
10*	10 - 12mm	55
12*	12 - 14mm	55
14	14 - 16mm	55
16	16 - 19mm	55
19	19 - 22mm	55
22	22 - 26mm	70
26	26 - 30mm	70
30	30 - 34mm	70
34	34 - 39mm	75
39	39 - 45mm	75
45	45 - 51mm	90
51	51 - 57mm	90
57	57 - 63mm	100
63	63 - 69mm	110
69	69 - 74mm	110
74	74 - 80mm	110
78*	78 - 87mm	110
