Portable Hydraulic Hose Crimper with 500T Crimping Force for 2 Inch Hose Size
Price:
Contact Us
MOQ:
1 Set
Delivery Time:
2 - 7 Working Days
Brand:
MENSION
Product Description
Gates Mobile Hydraulic Hose Crimper Portable Hydraulic Hose Crimping Machine Two Inches
PORTABLE HYDRAULIC HOSE CRIMPER MS-51KH
DESCRIPTION
MS-51KH hose crimping machine is compact in structure, but powerful in crimping capacity. With high quality piston pump, it can crimp big size hydraulic hose with low noise.
MAIN FEATURES
- Accurate crimping with high precision dial
- High pressure but very safe
- Low maintenance cost
- Easy to learn
TECHNICAL DATA
| Model | MS-51KH Portable Hydraulic Hose Crimper |
|---|---|
| Crimping Range | 14 - 87 (mm) |
| Crimping Force | 500 (T) |
| Hose Size | 1/4 - 2 (inch) |
| Max. Opening | 30 (mm) |
| Die Sets | 10 |
| Die Set Type | 51 |
| System Pressure | 31.5 (Mpa) |
| Accuracy | 0.05 (mm) |
| Control | MS |
| Standard Voltage | 220 (V) / 380 (V) |
| Motor Power | 3 (KW) |
| Length | 670 (mm) |
| Width | 430 (mm) |
| Height | 1520 (mm) |
| Weight | 310 (KG) |
51 SERIES CRIMPER DIE SETS
| Die No. | Crimping Range | Length |
|---|---|---|
| 6* | 6 - 8mm | 35 |
| 8* | 8 - 10mm | 35 |
| 10* | 10 - 12mm | 35 |
| 12* | 12 - 15mm | 35 |
| 15 | 15 - 19mm | 60 |
| 19 | 19 - 23mm | 60 |
| 23 | 23 - 26mm | 60 |
| 26 | 26 - 31mm | 60 |
| 31 | 31 - 36mm | 70 |
| 36 | 36 - 41mm | 70 |
| 41 | 41 - 47mm | 70 |
| 47 | 47 - 55mm | 80 |
| 55 | 55 - 63mm | 80 |
| 63 | 63 - 69mm | 80 |
| 69* | 69 - 76mm | 100 |
NOTE
- * for non standard die sets
- Customized die sets are available
- Special voltage 110V, 208V, 240V, 415V are available
