C60 1.0601 Forged Round Bar Carbon Steel Round Bar Diameter φ150-1500mm
C60 1.0601 forged round bar carbon steel round bar C60 steel bar C60 steel Manufacturer
C60 grade steel is a medium carbon steel with good tensile strengths. Although this grade is capable of through hardening by quenching and tempering on limited sections, it is more commonly supplied in the untreated or normalised condition.
Forged Round Bar C60 1.0601 Product features
| Material | C60 1.0601 |
| Type | Forged bar ,round ,square, flat, block, shaft etc. |
| Diameter | φ150-1500mm |
| Length | Max 10000mm (10m) |
| Surface | Black, peeled, polishing, bright, sand blast, hair line, etc. |
| Application | Wheels, rims, toothed shafts, cylinders, shafts, axles, pins, screwdrivers, pliers and similar items. |
| Tensile strength test | DIN EN ISO 6892-1 |
| Impact test | DIN EN ISO 148-1 |
| UT | DIN EN10228 Quality-Class 3 C/c or D/d |
| Grain size | ASTM E112 / EN ISO 643 |
| Applicable standard | EN10250,EN10083,SEW550 etc |
| Certificate | EN 10204 / 3.1 3.2 |
Forged Round Bar C60 1.0601 Chemical Compostion
| Standard | Steel designation name | Number | C | Si Max |
Mn | P Max |
S Max |
Cr Max |
Mo Max |
Ni Max |
Cr+Mo+Ni Max |
Al Min |
| EN10250 | C60 | 1.0601 | 0.57-0.65 | 0.40 | 0.60-0.90 | 0.045 | 0.045 | 0.40 | 0.10 | 0.40 | 0.63 | - |
Forged Round Bar C60 1.0601 Permissible deviations
| Permissible deviations between the producct analysis and the limiting values given in Table 1 for the cast analysis EN10250 |
||
| Element | Permissible maximum content in the cast analysis % | Permissible deviation % |
| Carbon | ＜0.55 | ±0.02 |
| ＞0.55 ≤0.65 | ±0.03 | |
| Silicon | ≤0.40 | ±0.03 |
| ＞0.40 | ±0.04 | |
| Manganese | ≤1.00 | ±0.04 |
| ＞1.00 ≤1.65 | ±0.06 | |
| Phosphorus | ≤0.045 | +0.005 |
| Sulfur | ≤0.045 | +0.005 |
| Chromium | ≤0.40 | +0.05 |
| Molybdenum | ≤0.10 | +0.03 |
| Nickel | ≤0.40 | +0.05 |
| Aluminium | ≥0.020 | -0.005 |
Forged Round Bar C60 1.0601 Mechanical properties
| Mechanical properties in the normalized and normalized and tempered conditions Thickness of ruling section tR |
||||||||||||||||||||||||||
| Steel designation |
tR≤100mm | 100＜tR≤250mm | 250＜tR≤500mm | 500＜tR≤1000mm3) | ||||||||||||||||||||||
| Standard | Name | Number |
Re min |
Rm min |
A min % | KV min J |
Re min |
Rm min |
A min% | KV min J |
Re min |
Rm min |
A min % | KV min J |
Re min |
Rm min |
A min% | KV min J | ||||||||
| l 1) | tr 1) | l 1) | tr 1) | l 1) | tr 1) | l 1) | tr 1) | l 1) | tr 1) | l 1) | tr 1) | l 1) | tr 1) | l 1) | tr 1) | |||||||||||
| EN10250 | C60 | 1.0601 | 340 | 670 | 11 | - | - | - | 310 | 650 | 11 | 8 | - | - | 275 | 630 | 11 | 8 | - | - | 260 | 620 | 10 | 7 | - | - |
Forged Round Bar C60 1.0601 Heat treatment
| Heat treatment EN10250 |
|||||
| Steel designation | Quenching temperature ℃ |
Cooling medium |
Tempering temperature ℃ |
Normalizing temperature ℃ |
|
| Name | Number | ||||
| C60 | 1.0601 | 800 to 840 | Oil or water | 550 to 660 | 820 to 860 |
