1300 kg Air Cooling Fresh Water Flake Ice Making Machine 3P/50Hz R22/R404R
Hot Selling 1300 kg Air Cooling Fresh Water Flake Ice Machine
| Product Parameter | |||||||
| Model | Daily Output (T/24h) | Cooling method | Compressor Power | Fan Power for Cooling Tower | Cooling Pump Power | Unit Size | Unit N.W. (KG) |
| (L*W*H mm) | |||||||
| BF 5000 | 5 | Water | 13.49 kw | 0.75 kw | 2.2 kw | 1900*1500*1470 | 1100 |
| BF 6000 | 6 | Water | 19.94 kw | 0.75 kw | 2.2 kw | 1900*1500*1470 | 1100 |
| BF 8000 | 8 | Water | 24.2 kw | 1.5 kw | 2.2 kw | 2400*1900*1860 | 1300 |
| BF 10000 | 10 | Water | 33.8 kw | 1.5 kw | 4 kw | 2500*2000*1860 | 1500 |
| BF 15000 | 15 | Water | 44.5 kw | 1.5 kw | 4 kw | 3350*2150*1960 | 3200 |
| BF 20000 | 20 | Water | 64 kw | 1.5 kw | 5.5 kw | 3400*2220*2230 | 4200 |
| BF 25000 | 25 | Water | 76.5 kw | 2.2 kw | 5.5 kw | 3700*2250*2510 | 4600 |
| BF 30000 | 30 | Water | 93.7 kw | 2.2 kw | 7.5 kw | 4700*2250*2520 | 5000 |
| BF 40000 | 40 | Water | 118 kw | 2.2 kw | 7.5 kw | 5000*2300*2700 | 7500 |
Compressor brand: Bizter / Hanbell; Refrigerant: R22/R404R.
Power supply: voltage 380 V/3P/50Hz
Operating conditions: T (water supply):20℃, T (ambient): 32℃, T (condensing): 38℃, T (evaporating): -20℃
Flake ice: Thin, dry and loose flakes of white ice. Flat shapeIrregular, 15 mm - 22 mm thick, diameter approximately 12 - 45 mm.
Flake ice is dry, soft and free of sharp edges and does not. They do not pierce the frozen object. The flat shape of the flake ice. The flat shape of the flake ice minimizes damage to the frozen object and protects the packaged food.
Flake ice has a large contact area, fast cooling, storage and transportation convenient, thorough mixing, reduce heat exchange, maintain the ice temperature, and has good moisturizing effect, etc.
1. Questions before quotation
A. Would you make ice from seawater, saltwater or freshwater?
B. Where and when would the machine be installed roughly?The ambient temperature and water inlet temperature?
C. What’s the power supply?
D. What is the application of the flake ice produced?
E. Which cooling mode would you prefer to? Water or air, Evaporative cooling?
2. Installation & commissioning
A. Installed by customers according to the manuals, online instructions and live video conference of ICEMEDAL.
B. Installed by ICEMEDAL engineers.
a. ICEMEDAL would arrange 1~3 engineers based on the projects to the installation sites for the final supervision of all installations and commissioning.
b. Customers need to provide local accommodation and round-trip ticket for our engineers and pay for the commissions.
c. Power, water, installation tools and spare parts need to be ready before ICEMEDAL engineers arrive.
3. Warranty & Technical support
A. 1 year after Bill of Lading date.
B. Any failure occurred within the period due to our responsibility, ICEMEDAL will supply the spare parts for free.
C.ICEMEDAL provide full technical support and training courses after equipment installation and commissioning.
C. Permanent technical support & consultation all life long for the machines.
D. Over 25 engineers for instant after-sale services and more than 15 are available for serving overseas.
