VMC1160 3/4/5 Axis CNC Vertical Machining Center Machine High precision

Price Negotiable

Price: 26000 USD/SET

MOQ: 1 set

Delivery Time: 30 working days

Brand: HR

Product Description

Items	Details	Unit	VMC1160
Table	Size	mm	1200×600
	Travel of 3 axis(X/Y/Z)	mm	1100/600/600
	Max, table load	kg	1000
T-slot	Size	mm	5-18×120
Spindle	Spindle taper		BT40
	Distance from Spindle center to Colum guide	mm	650
	Distance of spindle head to table	mm	130-780
	Max speed	rpm	8000
	Motor power	KW	11/15
Accuracy	Positioning accuracy(X/Y/Z)	mm	±0.01/±0.008/±0.008
Accuracy	Repeatability(X/Y/Z)	mm	±0.005
Axis motor	Power of X/Y/Z	Kw	2.5/2.5/2.5
Axis motor	Torque of X/Z	Nm	16/24
Feeding speed	Rapid feed of X/Y/Z	m/min	36/36/24(linear guide way)
	Cutting feed of X/Y/Z	m/min	10
	Weight	Kg	7800
	Dimension	mm	330028002700
	Power	V	3 phase 380V,

The vmc1160 Cheap 3 axis cnc milling machine with CE certificate feed shaft is controlled by X, Y and Z three dimensions, and spindle is driven by frequency power. It could realize one-time clamping upon various plates, boards, shells, cam, molds and etc. complex components, it can also complete drilling, milling, boring, expanding, reaming, tapping and etc. multiple processing; this machine is applied to produce various and middle & large batch of components, especially for machining of complex and
high-precision components.

Detailed description
