Super Arch Rubber Fender Corrosion Resistant Long Service Life Impact Resistant
Super Arch Rubber Fender Corrosion Resistant Long Service Life Impact Resistant
Description
Our Eco-Friendly V-Fender is designed for sustainable marine protection, using recyclable rubber materials without compromising performance. The V-profile design efficiently absorbs kinetic energy, safeguarding both ships and dock structures. Resistant to oil, chemicals, and saltwater, it ensures longevity in demanding environments. Perfect for green port initiatives, this fender reduces environmental impact while delivering high safety standards. Lightweight yet durable, it simplifies installation and replacement. Choose our V-Fender for an eco-conscious approach to marine infrastructure.
Specifications
|
Product Name |
Dock Rubber Fender |
|
|
Material |
Natural rubber, Silicone rubber |
|
|
Colour |
Black, or customized |
|
|
Surface |
Smooth |
|
|
Size |
Height |
200-1000mm |
|
Length |
1000-3500mm |
|
|
All sizes can be customized |
||
|
Physical Properties |
Polymer Content |
100% virgin |
|
Working temperature |
-50℃~240℃ |
|
|
Tensile strength |
≥16 mpa |
|
|
Density |
90+/-5 Per 100mm in |
|
|
Hardness |
50-70 (shore A) |
|
|
Elongation |
≥400% |
|
|
Features |
1. Through high temperature resistant |
|
|
2. Excellent tear resistant, oil resistant, aging resistant |
||
|
3. Resistant to industrial acid & alkali and good elastic |
||
|
4. Built as per PIANC2002 |
||
|
Application |
Multi-Purpose-Terminals, RoRo ramps, Passenger Vessel Terminals, Barge |
|
|
Model |
W |
B |
F |
C |
H |
|
[mm] |
[mm] |
[mm] |
[mm] |
[mm] |
|
|
HM-DRF200H |
400 |
320 |
145 |
128 |
200 |
|
HM-DRF250H |
500 |
410 |
175 |
160 |
250 |
|
HM-DRF300H |
600 |
490 |
225 |
196 |
300 |
|
HM-DRF400H |
800 |
670 |
300 |
260 |
400 |
|
HM-DRF500H |
1000 |
840 |
375 |
325 |
500 |
|
HM-DRF600H |
1200 |
1010 |
450 |
390 |
600 |
|
HM-DRF800H |
1600 |
1340 |
600 |
520 |
800 |
|
HM-DRF1000H |
2000 |
1680 |
750 |
650 |
1000 |
Features
Easy Installation
Pre-designed with standard mounting options (bolted, welded, or suspended).
Customizable Sizes & Hardness
Available in various dimensions and Shore A hardness levels to fit different berthing needs.
Long Service Life
Engineered to last 10+ years even in demanding marine environments.
Shock Absorption Efficiency
Minimizes vessel rebound for safer and smoother docking.
Applications
● Floating docks
● Bridge protection systems
● Waterfront structures
● LNG terminals
Advantages
Anti UV Ozone Resistant
Enhanced longevity under sunlight and harsh weather.
Saltwater Chemical Resistance
Withstands corrosive marine environments.
Abrasion Proof Surface Treatment
Reduces wear from ship contact.
Wide Temperature Tolerance (-40°C to +80°C)
Reliable in Arctic to tropical conditions.
FAQ
1. Q: Do you provide installation guidance?
A: Yes, detailed installation manuals and on-site support are available.
2. Q: What quality certifications do you have?
A: ISO 9001, PIANC standards, and CE certification.
3. Q: Can your fenders be used in freshwater and saltwater?
A: Yes, they perform well in both environments.
4. Q: What's the lead time for standard products?
A: 2-4 weeks for standard sizes, 6-8 weeks for custom orders.
