Submarine Fenders with Low Reaction Force Wear Resistant Shock Buffer Performance for Marine Docking
Hongruntong Marine Submarine Fenders are high-performance marine protection systems designed for submarine docking operations, underwater maintenance facilities, offshore engineering platforms, and specialized shipyard applications.
Manufactured using premium marine-grade rubber compounds combined with reinforced synthetic elastomers, these fenders deliver excellent energy absorption performance, low reaction force, and superior resistance to harsh marine environments.
The advanced structural design allows the fenders to absorb heavy berthing impact while minimizing concentrated pressure on submarine hull surfaces. This is especially important for modern submarines equipped with sensitive outer coatings and precision structural components.
A European submarine overhaul facility upgraded its docking infrastructure after experiencing excessive vibration transfer and hull coating wear during berthing operations for 5,000-ton submarines. Hongruntong Marine supplied a customized submarine fender system with reinforced cylindrical rubber units and enhanced compression recovery capability. After installation, docking stability improved significantly, vibration transfer to dock structures was reduced, and the customer reported lower maintenance costs and more efficient vessel positioning procedures during daily operations.
| Parameter | Value |
|---|---|
| Product Name | Submarine Fenders |
| Material | SBR, NR |
| Size Available | 3.3*10.6M |
| Tensile Strength | ≥ 18 MPA |
| Density | 90+/-5 |
| Color | Black |
| Application | Submarine, ferry, oil rigs and so on |
| Hardness | 40-70 Shore A |
| Elongation | ≥ 400 |
| Tear Strength | ≥ 400 N/cm |
| Breaking Strength | >310 |
| Chemical | Resistance |
|---|---|
| Fuel A | No deterioration |
| Oil 3 | No deterioration |
| Lubricating oil | No deterioration |
| Cutting oil | No deterioration |
| Dilute HCL | No deterioration |
| Diameter x Length (mm x mm) | Initial Internal Pressure (kPa) | Ship Radius (mm) | Water Ratio (%) | Guaranteed Energy Absorption (kJ) | Reaction Force at GEA (kN) | Hull Pressure at GEA (kPa) | Deflection at GEA (%) |
|---|---|---|---|---|---|---|---|
| 1500 x 6100 | 50 | 3000 | 60% | 131 | 562 | 140 | 51% |
| 80 | 186 | 754 | 188 | ||||
| 1700 x 7200 | 50 | 4000 | 65% | 167 | 682 | 137 | 47% |
| 80 | 239 | 918 | 184 | ||||
| 2000 x 6000 | 50 | 4000 | 70% | 135 | 544 | 131 | 41% |
| 80 | 194 | 736 | 177 | ||||
| 2500 x 5500 | 50 | 4500 | 65% | 225 | 769 | 135 | 41% |
| 80 | 322 | 1035 | 182 | ||||
| 2500 x 7700 | 50 | 4500 | 70% | 326 | 1016 | 136 | 41% |
| 80 | 470 | 1368 | 183 | ||||
| 3300 x 6500 | 50 | 4500 | 75% | 307 | 887 | 127 | 35% |
| 80 | 442 | 1203 | 173 | ||||
| 3300 x 10600 | 50 | 5000 | 65% | 1003 | 2137 | 142 | 47% |
| 80 | 1429 | 2863 | 190 | ||||
| 4500 x 9000 | 50 | 5000 | 60% | 1439 | 2401 | 138 | 46% |
| 80 | 2059 | 3228 | 185 | ||||
| 4500 x 12000 | 50 | 6000 | 65% | 1977 | 3198 | 141 | 46% |
| 80 | 2819 | 4277 | 189 |
Hongruntong Marine Submarine Fenders are engineered to provide excellent energy absorption while maintaining controlled reaction force during docking procedures. The internal rubber structure is carefully designed to deform progressively under impact, allowing docking energy to dissipate smoothly across the fender body instead of concentrating pressure on a single contact point. This reduces stress on submarine hull structures and minimizes the possibility of coating damage or structural fatigue.
Repeated docking operations can reduce the effectiveness of ordinary marine fenders over time. Hongruntong Marine uses advanced rubber compounding technology and precision vulcanization processes to ensure excellent elastic recovery after repeated compression cycles. The fenders maintain stable dimensions, consistent energy absorption performance, and reliable structural integrity even under intensive operational schedules.
Marine environments expose docking systems to continuous seawater contact, UV radiation, ozone, humidity, and temperature fluctuations. Hongruntong Marine Submarine Fenders are manufactured using anti-aging rubber compounds specifically developed for long-term marine exposure. The rubber structure resists cracking, hardening, abrasion, and environmental degradation even after years of operation in coastal and offshore environments.
Different docking facilities require different installation methods depending on berth structure, submarine size, tidal conditions, and operational requirements. Hongruntong Marine provides customized installation solutions including suspended chain systems, fixed mounting structures, modular support frames, and reinforced connection assemblies.
- Submarine Berthing Facilities: Submarine fenders are widely installed in dedicated docking stations where submarines require stable berthing conditions and precise hull protection during routine docking procedures.
- Floating Dry Dock Operations: Floating dry docks use submarine fenders to stabilize vessels during inspection, maintenance, and repair procedures.
- Offshore Engineering Platforms: Offshore support stations and underwater engineering platforms require reliable marine protection systems for submarine transfer and support operations.
- Professional Experience in Marine Fender Engineering: Extensive experience in designing and manufacturing advanced marine fender systems for shipyards, ports, offshore platforms, and submarine docking facilities worldwide.
- Strict Quality Control and Premium Raw Materials: High-quality natural rubber and reinforced synthetic elastomers sourced from qualified suppliers to ensure excellent mechanical strength and long-term durability.
- Advanced Customization Capability: Comprehensive customization services based on vessel displacement, docking speed, berth structure, environmental conditions, and operational frequency.
- Reliable Technical Support and After-Sales Service: Complete technical assistance throughout the entire project lifecycle including engineering consultation, product selection guidance, and installation recommendations.
