Customized Heavy Duty D Type Fenders PIANC2002 300H Hollow D For Marine Dock Ship
Customized Heavy Duty D Type Fenders PIANC2002 300H Hollow D Marine Dock Ship
Description
D type rubber fenders have become increasingly popular due to the high versatility and excellent protection that they offer. The fenders are designed to be securely attached to many surface types using bolts. Many of the D type fenders we offer are available pre-drilled, which ensures that the bolts are evenly spaced out and also greatly reduces installation times. We also offer the option of providing your fenders pre-curved, chamfered and cut to specific lengths. This ensures that they maintain a perfect fit and allows you install the product as soon as it arrives.
Specifications
| Product Name | Customized Heavy Duty D Type Fenders PIANC2002 300H Hollow D Marine Dock Ship |
| Brand Name | DockFender |
| Model Number | DF-D300H |
| Material | High Performance Natural Rubber |
| Standard | HGT2866-2016, PIANC2002 |
| Shape | D Shape |
| Package | Plastic Bag + Pallet |
| Feature | High E/R.H value, wear-resisting |
| Part | Dock Bumper |
| Usage | For ship docking or berthing |
| Certificate | DNV BV CCS LR ABS |
| Color | Customers' Requirements |
| Working Temperature | -15 degreee to 200 degree |
| A | B | C | D | E | F | H | K |
| [mm] | [mm] | [mm] | [mm] | [mm] | [mm] | [mm] | [mm] |
| 70 | 30 | 15 | 30 | 45 | 80 | 90 - 130 | 200 - 300 |
| 100 | 45 | 15 | 30 | 50 | 100 | 90 - 130 | 200 - 300 |
| 125 | 60 | 20 | 40 | 60 | 125 | 110 - 150 | 250 - 300 |
| 150 | 75 | 20 | 40 | 75 | 150 | 110 - 150 | 250 - 300 |
| 150 | 80 | 25 | 50 | 100 | 200 | 130 - 180 | 300 - 400 |
| 200 | 100 | 25 | 50 | 100 | 200 | 130 - 180 | 300 - 400 |
| 200 | 100 | 30 | 60 | 125 | 250 | 140 - 200 | 350 - 450 |
| 250 | 125 | 30 | 60 | 125 | 250 | 140 - 200 | 350 - 450 |
| 300 | 150 | 30 | 60 | 150 | 300 | 140 - 200 | 350 - 450 |
| 350 | 175 | 35 | 75 | 175 | 350 | 140 - 200 | 350 - 450 |
| 380 | 190 | 35 | 75 | 190 | 380 | 140 - 200 | 350 - 450 |
| 300 | 150 | 35 | 75 | 175 | 400 | 140 - 200 | 350 - 450 |
| 400 | 200 | 35 | 75 | 200 | 400 | 140 - 200 | 350 - 450 |
| 500 | 250 | 45 | 90 | 250 | 500 | 160 - 230 | 400 - 500 |
| *Note: Other sizes can be customized according to the requirements. | |||||||
| A | B | C | D | E | F | G | H | K |
| [mm] | [mm] | [mm] | [mm] | [mm] | [mm] | [mm] | [mm] | [mm] |
| 100 | 25 | 10 | 30 | 15 | 100 | 50 | 90 - 130 | 200 - 300 |
| 150 | 30 | 12 | 65 | 20 | 150 | 75 | 110 - 150 | 250 - 350 |
| 200 | 45 | 15 | 75 | 25 | 200 | 100 | 130 - 180 | 300 - 400 |
| 250 | 50 | 20 | 100 | 30 | 250 | 125 | 140 - 200 | 350 - 450 |
| 300 | 60 | 25 | 125 | 30 | 300 | 150 | 140 - 200 | 350 - 450 |
| 350 | 70 | 25 | 150 | 35 | 350 | 175 | 140 - 200 | 350 - 450 |
| 400 | 80 | 30 | 175 | 35 | 400 | 200 | 140 - 200 | 350 - 450 |
| 400 | 80 | 30 | 200 | 35 | 400 | 200 | 140 - 200 | 350 - 450 |
| 500 | 100 | 30 | 250 | 35 | 500 | 250 | 140 - 200 | 350 - 450 |
Features
1. Highly durable rubber fender.
2. Popular D type extrusion.
3. Tough rubber bumper.
4. Can be supplied in long lengths.
5. Easy to install.
6. Can be supplied in non-marking colours.
Applications
● Workboats & tugboats.
● Pilot boats.
● Quays & piers & harbors.
● Small crafts.
● Warehouses & frame docks.
Advantages
◆ Fully compliant with PIANC2002.
◆ IACS can be provided for free.
◆ 100% imported raw materials, strict production process.
◆ The series of moulds can meet the requirements of various sizes.
◆ Third party quality inspection to ensure that each product is qualified for delivery.
