Small Size Auto Drain Valve GSB2 GSB4 GSB6 GSB8 Lever Float Steam Traps

Small Size GSB2, GSB4, GSB6, GSB8 Lever Float Steam Traps

 I. Overview

    GSB8 Lever Float Steam Trap GSB6 Large Displacement Lever Float Trap/GM2, GM4, GM6, GM8 Lever Float Trap/GSB2, GSB4, GSB6, GSB8 Lever Float Trap/Stainless Steel Lever Float Trap is widely used in petrochemical, metallurgy, papermaking, food and other industrial steam equipment, dryers and various large heat exchangers, etc., especially suitable for condensate large displacement work occasions.

2.Main overall dimensions

 3. Use and maintenance

    Fire gate valves are often used in automatic sprinkler fire pipeline systems, rotating handwheels to control the opening and closing of water sources in water supply pipelines.

4. Installation:

(1) Handwheels, handles and transmission mechanisms are not allowed to be used for lifting, and collisions are strictly prohibited.

(2) Before installation, check whether the product model, tag and specification are consistent, and check whether the parts of the whole machine are defective and loose.

(3) Before installation, the pipeline should be cleaned, and there should be enough straight pipe section at the valve inlet, and equipped with a filter.

(4) The installation site should consider the comprehensive personnel and equipment, even if it is operated, it is conducive to disassembly and maintenance.

(5) The signal box is connected to the fire protection system circuit.
