400-1200mm Steel Slitting Machine Low Carbon Steel Coil Slitting Line
steel slitting machine / coil slitting machine / roll slitting machine
The model and basic parameters
| Item Model | YJFT-400 | YJFT-600 | YJFT-800 | YJFT-1250 | YJFT-1600 | YJFT-2000 | Custom-size |
| Max Feed Width(mm) | 400 | 600 | 800 | 1250 | 1600 | 2000 | / |
| Thickness(mm) | Custom-size | Custom-size | Custom-size | Custom-size | Custom-size | Custom-size | / |
| Speed(m/min) | 0-90 | 0-90 | 0-80 | 0-80 | 0-60 | 0-50 | / |
| Equipment composition |
uncoiler→Straighten→Shear→guide→Slitting→Article→ Recoiler |
||||||
| Remark | If you have any question, please contact us freely! | ||||||
Summary
This equipment is specially used for producingΦ12.7-Φ38.1mm, δ0.4-2.0mm high-frequency straight seam welded pipe and corresponding square pipe (10*10-30*30mm,0.4-1.5mm). The composition of equipment is from uncoiler to fixed length cutting saw. Rolling speed can be according to suitable range of pipe diameter and wall thickness.
Applicable material
1 Raw material: Low-carbon steel,
4 I.D. of steel coil: Φ450-Φ550mm
5 O.D. of steel coil: Φ800-Φ1200mm
6 Maximum weight coil: 2500kgs
Q:Are you manufacturer?
A:Yes,we are manufacturer.We have our own technical team and factory. Welcome to visit us.
Q:What kind o f payment term you can do?
A:We are flexible about payment terms,please contact us for details.
Q:What info you need before you make the proposal?
A:The pipe diameter and thickness range which you need or the profile drawings,material information,your special requirements.
Q: What should I do if I just start a new business?
A:Contact us immediately ,we provide free consultant pre-sales service.Also we can help you to solve the material(steel coil)purchase,worker train,international market price.
Q:How do you do QA?
A:We have special team do strict QA,this is our strengths:
(1)Every gear box will be tested for 8 hours with oil inside to guarantee there is no leak.
(2)Every shaft will be inspected for the centering jumpiness.
(3)Every roller will be checked to make sure its in the range of tolerance critical parts will be inspected for all dimensions.
Q:Why I should choose you,what are the differences between you and other Chinese suppliers?
A:We are concentrate on this area for more than 20 years,and especially our company’s YJ series spiral accumulator won a utility model patent certificate issued by intellectual property office (patent no:ZL200820132936.X).Our pipe making machine line directly export to Russia,Vietnam,India,Indonesia,and many countries in Asia.
