D18 PCD Wire Drawing Die Setup Polycrystalline Diamond Dies

D18 PCD Wire Dies, Wire Drawing Dies, Polycrystalline Diamond Dies

1. Description:

PCD Wire Drawing Die has the longest die life of all materials,which can provide the highest production efficiency and reduce downtime. PCD Core is a kind of artificially sintered diamond,which can be used in all wet drawing and dry drawing processes, polycrystalline diamond high temperature pressing and alloy bond sintering. The maximum recommend hole of D18 is 2.0mm.

2. Specifications:

Note: The above hole sizes are recommended for soft wire.In case of hard wire drawing,the maximum hole size should not exceed 65% of them.

3. Application:

It is suitable for all applications from large drawing to ultra-fine drawing,with predictable wire surface quality.

4. Advantage:

The wire drawing die is a very important and consumable product used by various metal wire manufacturers to draw wires. The application range of wire drawing dies is very wide, mainly used for drawing straight and difficult-to-machine objects such as bars, wires, wires, pipes, etc., and generally suitable for drawing processing operations of metal and alloy materials such as steel, copper, tungsten, molybdenum, etc. . Since the cost of the wire drawing die can reach more than half of the wire drawing cost, how to reduce the consumption cost of the wire drawing die and increase its service life is the primary problem that metal wire production units urgently need to solve.
