Automatic Mask Horizontal Cartoning Machine Feeding Case Packers
Automatic Horizontal Face Mask Cartoner Packaging Machine with Automatic Feeding Device
Cartoner Packaging Machine Introduction
This machine is suitable for granule bag, soft double aluminum, paste, band-aid, facial mask, coffee bag and other similar bag items automatic feeding and packing. On-line MATERIAL INSPECTION, MANUAL FOLDING (1 to 4 times folding) and transmission, carton suction forming and transmission, material into the box, embossing batch number, paper tongue packaging at both ends of the carton (also applicable to hot melt adhesive), missing material removal and finished product output and other processes are automatically completed.
Technical Parameter
| Model | XQ-ZH100 | |
|
Box |
Quality Requirement | 300-450g/m² |
| Dimension Range | (75-220)mm×(100-175)mm×(16-80)mm | |
| Production Capacity | 30-100pcs / min | |
| Total Power | 1.5kw | |
| Working Voltage | 220V/380V 50Hz | |
| Instruction Leaflet Size | Quality Requirement | 60-70g/m² |
| Unfolded Dimension | (80-250)mm×(90-170)mm | |
| Folded Dimension | 1-4 folded | |
| Compressed Air | Working Pressure | ≥0.5Mpa |
| Air Consumption | 120-160L/min | |
| Machine Weight | 1300kg | |
| Machine Dimensions | 4300mm×1300mm×1900mm | |
Cartoning Machine Features
Model:XQ-ZH100 Automatic Bottle Carton Packing Machine Cartoner Packaging Machine for Medical Cosmetics with Automatic Feeding Device
■PLC automatic control system, frequency conversion speed control, electrical components are all international famous brands.
■ Man-machine interface operating system.
■ Mechanical overload automatic shutdown.
■ Automatic elimination of the lack of packaging and instructions of the carton.
■ Fault display, alarm and finished product count.
