5-500g High Accuracy Checkweigher 150pcs/Min Case Checkweigher For Food Medicine
5-500g Product High Accuracy Checkweigher with 150pcs/min for Food Medicine
Checkweigher Introduction
A checkweigher is an automatic or manual machine for checking the weight of packaged commodities. It is normally found at the offgoing end of a production process and is used to ensure that the weight of a pack of the commodity is within specified limits.
Technical Parameter
| Model | XQ-CZ150 | |||||||||
| Weighing Scope | 5-500g | |||||||||
| Weighing Accuracy | ±0.1g (depends on product) | |||||||||
| Minimum Scale | 0.1g | |||||||||
| Max. Speed | Max 150pcs/min | |||||||||
| Product Limit | L | 200mm | ||||||||
| W | 150mm | |||||||||
| H | 3-200mm | |||||||||
| Operating Mode | Touch screen | |||||||||
| Operation Interface | 7 inch touch screen | |||||||||
| Removing Type | Push plate removal/air blowing removal | |||||||||
| The Height from Ground to Belt | 750±50mm (can be customized) | |||||||||
| Machine Structure | Stainless steel (SUS304) | |||||||||
| Working Voltage | AC110V/220V 50-60HZ | |||||||||
| Power | About 100w | |||||||||
| Working Table Dimension | 316mmX150mm | |||||||||
| Machine Weight | About 60kg | |||||||||
| Optional | alarm light, RS485 output port, eliminate box | |||||||||
| Remark | The properties and environment of the tested products are different, and the detection speed and accuracy are also different. The actual test is taken as the standard. | |||||||||
Checkweigher Features
Model: XQ-CZ150 5-500g Product High Accuracy Checkweigher with 150pcs/min for Food Medicine
- Password protection is set for parameter, only for management personnel.
- Automatic zero tracking system to ensure reliable detection data.
- Independent research and development of single-chip microcomputer system, unique filtering algorithm, to ensure the stability of the system.
- Simple mechanical structure, buckle conveyor belt, easy to disassemble, clean and maintain.
- Machine structure is made of stainless steel 304.
