200pcs/Min Biscuit Bag Food Checkweigher In Motion Small Bag High Accuracy
Small Bag High Accuracy Checkweigher 200pcs/min for Food
Automatic Biscuit Bag High Accuracy Checkweigher 200pcs/min for Food
Checkweigher Introduction
A checkweigher is an automatic machine for checking the weight of packaged products. Any packs that are outside the tolerance are taken out of line automatically. Checkweighers are widly used in cleanrooms, mints (rolls of coins), dry atmosphere environments, wet environments, produce barns, food processing, drug processing, cosmetics filling, etc.
Technical Parameter
| Model | XQ-CZ100 | |||||||||
| Weighing Scope | 2-300g | |||||||||
| Weighing Accuracy | ±0.05g (depends on product) | |||||||||
| Minimum Scale | 0.01g | |||||||||
| Max. Speed | Max 200pcs/min | |||||||||
| Product Limit | L | 100mm | ||||||||
| W | 100mm | |||||||||
| H | 2-150mm | |||||||||
| Operating Mode | Touch screen | |||||||||
| Operation Interface | 7 inch touch screen | |||||||||
| Removing Type | Blow away | |||||||||
| The Height from Ground to Belt | 750±50mm (can be customized) | |||||||||
| Machine Structure | Stainless steel (SUS304) | |||||||||
| Working Voltage | AC110V/220V 50-60HZ | |||||||||
| Power | About 100w | |||||||||
| Working Table Dimension | 200mmX100mm | |||||||||
| Machine Weight | About 60kg | |||||||||
| Optional | alarm light, RS485 output port, | |||||||||
| Remark | The properties and environment of the tested products are different, and the detection speed and accuracy are also different. The actual test is taken as the standard. | |||||||||
Checkweigher Features
Model: XQ-CZ100 Automatic High Accuracy Checkweigher with reject system
- Test data of 100 kinds of products can be set and stored to facilitate user switching.
- Automatic photoelectric detection with empty bag, adjustable conveyor belt speed, automatic learning function.
- Password protection is set for parameter, only for management personnel.
- Automatic zero tracking system to ensure reliable detection data.
