40pcs/Min Electromechanical Auto Check Weigher Big Carton Dynamic
Automatic High Accuracy Checkweigher for Big Carton 40pcs/min
Checkweigher Introduction
Checkweigher is an electromechanical system that can control the weight of products on the production line without stopping, and automatically discard products whose weight exceeds the specified range. The calibration scale designed by SICI AUTO is an innovative solution to meet the production requirements of the industry.
Technical Parameter
| Model | XQ-CZ450 | |||||||||
| Weighing Scope | 0.05-30kg | |||||||||
| Weighing Accuracy | ±5-20g (depends on product) | |||||||||
| Minimum Scale | 1g | |||||||||
| Max. Speed | Max 40pcs/min | |||||||||
| Product Limit | L | 400mm | ||||||||
| W | 450mm | |||||||||
| H | 5-400mm | |||||||||
| Operating Mode | Touch screen | |||||||||
| Operation Interface | 7 inch touch screen | |||||||||
| Removing Type | Push plate | |||||||||
| The Height from Ground to Belt | 750±50mm (can be customized) | |||||||||
| Machine Structure | Stainless steel (SUS304) | |||||||||
| Working Voltage | AC110V/220V 50-60HZ | |||||||||
| Power | About 100w | |||||||||
| Working Table Dimension | 700mmX450mm | |||||||||
| Machine Weight | About 120kg | |||||||||
| Optional | alarm light, RS485 output port, | |||||||||
| Remark | The properties and environment of the tested products are different, and the detection speed and accuracy are also different. The actual test is taken as the standard. | |||||||||
Checkweigher Features
Model: XQ-CZ450 Automatic High Accuracy Checkweigher for Big Carton 40pcs/min
- User-friendly operating system.
- Chinese-English interface.
- Weight of products can be compensated.
- Product qualification ratio can be showed in line graphs and bar charts.
- Large color LCD touch screen interface, simple operation and intuitive display.
- Support customized multi-language, the default is Chinese and English.
- Test data of 100 kinds of products can be set and stored to facilitate user switching.
- Automatic photoelectric detection with empty bag, adjustable conveyor belt speed, automatic learning function.
Samples
