40pcs/Min 100w Automatic Checkweigher 50hz In Line Checkweigher For Packing Line
40pcs/min Heavy Carton High Accuracy Checkweigher for Packing Line
Checkweigher Introduction
An automatic checkweigher incorporates a series of conveyor belts. These checkweigher are known also as belt weighers in-motion scales, conveyor scales, dynamic scales, and in-line scales. In filler applications, they are known as check scales. Typically, there are three belts or chain beds
A checkweigher can weigh 40pcs big items per minute (depending on carton size and accuracy requirements). Checkweighers can be used with metal detector and X-ray machines to enable other attributes of the pack to be checked and acted upon accordingly.
Technical Parameter
| Model | XQ-CZ450 | |||||||||
| Weighing Scope | 0.05-30kg | |||||||||
| Weighing Accuracy | ±5-20g (depends on product) | |||||||||
| Minimum Scale | 1g | |||||||||
| Max. Speed | Max 40pcs/min | |||||||||
| Product Limit | L | 400mm | ||||||||
| W | 450mm | |||||||||
| H | 5-400mm | |||||||||
| Operating Mode | Touch screen | |||||||||
| Operation Interface | 7 inch touch screen | |||||||||
| Removing Type | Push plate | |||||||||
| The Height from Ground to Belt | 750±50mm (can be customized) | |||||||||
| Machine Structure | Stainless steel (SUS304) | |||||||||
| Working Voltage | AC110V/220V 50-60HZ | |||||||||
| Power | About 100w | |||||||||
| Working Table Dimension | 700mmX450mm | |||||||||
| Machine Weight | About 120kg | |||||||||
| Optional | alarm light, RS485 output port, | |||||||||
| Remark | The properties and environment of the tested products are different, and the detection speed and accuracy are also different. The actual test is taken as the standard. | |||||||||
Checkweigher Features
Model: XQ-CZ450 40pcs/min Heavy Carton High Accuracy Checkweigher for Packing Line
- User-friendly operating system.
- Support customized multi-language, the default is Chinese and English.
- Weight of products can be compensated.
- Product qualification ratio can be showed in line graphs and bar charts.
- Large color LCD touch screen interface, simple operation and intuitive display.
- Support customized multi-language, the default is Chinese and English.
- Test data of 100 kinds of products can be set and stored to facilitate user switching.
- Automatic photoelectric detection with empty bag, adjustable conveyor belt speed, automatic learning function.
