Cosmetics Double Side Sticker Labeling Machine 80pcs/Min Pharma Bottle
Double Sides Sticker Labeling Sealing Machine for Cosmetics
- Product Description
It is a side labeling machine to seal bottom and top of carton, it is also suitable for single or double side labeling of products which improves production efficiency and is widely used in daily chemicals, cosmetics, petrochemicals, pharmaceuticals and other industries.
- Technical Parameter
| Model | XQ-TBS-Z |
| Labeling speed | 0—80pcs/min (Depending on the size of the bottle and the length of the label) |
| Drive Type | Electric |
| Suitable label |
Adhesive clear or printed sticker, in various shape of rectangles, squares, ellipses, and circle |
| Product Size | L50-200mm*W40-180mm*H30-150mm |
| Label Size | L10-150mm*W8-100mm or Dia. 10-40mm, customized |
| Conveying height | 850mm |
| Label roll | Outer Dia. 360mm, inner Dia. 76mm |
| Labeling accuracy | ±1mm(Not calculate the error of bottle and label) |
| Machine size (mm) | 2800*1700*1550mm |
| Power supply | 220V /50hz (Can be customized) 3.5kw |
-
Working Principle
The sensor detects the passing of the product, and sends a signal back to the labeling control system. The control system controls the sending of the label at the appropriate position and attaches it to the position where the product is to be labelled. The product flows through the labeling device, and the label is attached to the product. The sticking action of the label is completed.
Process: Put the product (can be connected to the assembly line) -> product delivery -> product separation -> labeling (automatic realization of the equipment) -> collect the labelled products.
-
