Lightweight P10.4 Rental LED Cabinet With Bevel Anti Bump Design
P10.4 lightweight rental LED cabinet 500*1000mm LMS-CLM Series bevel anti-bump design
Description:
Outdoor Rental Transparent Screen is sealed by silicon, Anti-UV, Anti-Dust and evading the led lens lowering phenomena. It is easily adaptable to intense temperatures and is moisture-proof and waterproof at the same time. It reduces the ageing speed & the screen can live for a long time.
Quick Detail:
· Carbon fiber structure
· High transparency
· LCD Visual monitoring
· System & PSU Backup
· Bevel anti-bump design
· Front maintenance design
Specifications:
|
Parameter Item |
LMS-CLM10.4-M3 |
| Pixel Pitch (mm) | 10.41 |
| Pixel Density (pixels/sqm) | 9,216 |
| Cabinet Resolution | 48x96 |
| Mask | Standard |
| Lamp Type | SMD3535 |
| Cabinet Size (mm) | 500 x 1000 x 77 |
| Cabinet Weight (kg) | 6.7(without cable) 7(with cable) |
| Brightness (cd/sqm) | 5000 |
| Gray Scale (Bit) | 14 |
| Color Temp (k) | 3500~9000 |
| Control System | Synchronous Control |
| Protection Level | IP65 |
| Intelligent Storage | No |
| Frame Frequency (Hz) | 50/60FPS |
| Refresh Rate(Hz) | 1920/3840(Optional) |
| Working Voltage | 100-240V AC, 50/60Hz |
| Power Consumption (W/ m²) | Max:≤600,Ave:≤200 |
| Lifetime (hrs) | 100,000 |
| Operating Temp (℃) | -20～+40 |
| Storage Temp (℃) | -35~+60 |
| Humidity Range(Rh) | 10%~90%, Non-condensing |
| Pixel Correction | Brightness And Color Correction |
Details about the product:
Applications:
Widely used in building exterior walls, shopping malls, outdoor advertising, etc.
