Polished Stainless Steel Angle Bar L V Shape 321 316 304 316l Ss Hot Rolled
Polished surface Hot Rolled Stainless Steel Angle Bar L V Shape 321 316 304 316l Ss stainless steel unequal equal angle
Descriptions
The corrosion resistance, mechanical properties, and versatility of stainless steel angle bars in grades 321, 316, 304, and 316L make them suitable for a wide range of applications, including:
High-Temperature Environments: Grade 321 angle bars are particularly suitable for applications involving elevated temperatures, such as heat exchangers, furnace components, and exhaust systems.
Marine and Coastal Structures: Grade 316 angle bars are used in marine environments, coastal construction, and seawater applications due to their excellent corrosion resistance against chlorides.
Chemical Processing: These angle bars find applications in chemical plants, refineries, storage tanks, and equipment subjected to corrosive chemicals and acids.
Product name | Stainless Steel Angle |
Standard | GB ASTM, JIS, SUS, DIN, EN etc |
Material | Stainless Steel |
Surface Finish | Polished , HL , Colour Pipe , Pickling |
Thickness | 0.8mm - 25mm |
Width | 25mm*25mm-200mm*125mm / 50mm*37mm-400mm*104mm |
Length | 1m - 12m , or according to your requests. |
Technique | Hot rolled, Cold rolled |
Usage | Mechanical & Manufacture, Steel strcuture, Shipbuilding, Bridging, Automobile Chassis. |
Another Name | U channel steel, channel steel, steel channel. |
Quality Test | We can offer MTC (Mill Test Certificate ) |
Stock or Not | Enough Stock |
Container Size | 20ft GP: 5898mm(Length)x2352mm(Width)x2393mm(High) 40ft GP: 12032mm(Length)x2352mm(Width)x2393mm(High) 40ft HC: 12032mm(Lengh)x2352mm(Width)x2698mm(High) |
| Grade | C | Si | Mn | P | S | Ni | Cr | Mo |
| 201 | ≤0.15 | ≤0.75 | 5.5-7.5 | ≤0.06 | ≤ 0.03 | 3.5-5.5 | 16.0-18.0 | - |
| 301 | ≤0.15 | ≤1.0 | ≤2.0 | ≤0.045 | ≤ 0.03 | 6.0-8.0 | 16.0-18.0 | - |
| 304 | ≤0.08 | ≤1.0 | ≤2.0 | ≤0.045 | ≤ 0.03 | 8.0-13.0 | 18.0-20.0 | - |
| 304L | ≤0.03 | ≤1.0 | ≤2.0 | ≤0.035 | ≤ 0.03 | 9.0-13.0 | 18.0-20.0 | - |
| 309S | ≤0.08 | ≤0.75 | ≤2.0 | ≤0.045 | ≤ 0.03 | 12.0-15.0 | 22.0-24.0 | - |
| 310S | ≤0.08 | ≤1.0 | ≤2.0 | ≤0.045 | ≤ 0.03 | 19.0-22.0 | 24.0-26.0 | - |
| 314 | ≤0.25 | ≤1.5-3.0 | ≤2.0 | ≤0.045 | ≤ 0.03 | 19.0-22.0 | 23.0-26.0 | |
| 316 | ≤0.08 | ≤1.0 | ≤2.0 | ≤0.045 | ≤ 0.03 | 10.0-14.0 | 16.0-18.0 | 2.0-3.0 |
| 316L | ≤0.03 | ≤1.0 | ≤2.0 | ≤0.045 | ≤ 0.03 | 10.0-15.0 | 16.0-18.0 | 2.0-3.0 |
| 321 | ≤0.08 | ≤1.0 | ≤2.0 | ≤0.035 | ≤ 0.03 | 9.013 | 17.0-19.0 | - |
| 347 | ≤0.08 | ≤0.75 | ≤2.0 | ≤0.045 | ≤ 0.03 | 9.0-13.0 | 17.0-19.0 | |
| 410 | ≤0.15 | ≤1.0 | ≤1.0 | ≤0.035 | ≤ 0.03 | - | 11.5-13.5 | - |
| 420 | ≤0.16-0.25 | ≤1.0 | ≤1.0 | ≤0.040 | ≤ 0.03 | - | 12.0-14.0 | - |
| 430 | ≤0.12 | ≤0.75 | ≤1.0 | ≤0.040 | ≤ 0.03 | ≤0.60 | 16.0-18.0 | - |
| 904L | ≤0.02 | ≤1.0 | ≤2.0 | ≤0.045 | ≤ 0.03 | 23.0-28.0 | 19.0-23.0 | - |
Details
Applications
Recommend Products
Packing & Shipping
Our Warehouse
Certificates
Market
FAQ
1. Q: do you provide samples? Is it free or extra?
A: Yes, we can provide samples free of charge, but freight and necessary taxes will be paid by you.
2. Q: how is your quality? How do you guarantee the quality?
A: our company has passed many certifications, each product has to go through 4-5 processes of inspection, with the corresponding quality test report and certificate. Welcome customers to our factory for inspection.
3. Q: How long is your delivery time?
A: For Stocks, we can send the goods to loading port wiyhin 7 days after receiving the deposit ;For production period,it usually needs about 15 days ~30 days after receiving the deposit.
4. Q: Where's your factory?
A: Our factory is in shandong afforded enough production ability and earlier delivery time.
