10.25 Inch Car Multimedia Player , Car Stereo Touch Screen For Mercedes Benz W204
10.25 inch 8 core 4gb ram 64gb rom car Display Stereo Android Radio for mercedes benz c class w204
|
Item |
Value |
|
Type |
Build-in 2DIN, 1 Din |
|
Placement |
Dashboard |
|
Screen Type |
LCD, VA, TN,IPS |
|
Function |
GPS, Stereo, Remote Control, Mirror Link, Split Screen, File Manager, Car Steering Wheel Control |
|
Connection |
Wifi,USB, BT, SD Card, TF Card |
|
Combination |
Built-in GPS, MP3 / MP4 Players, Radio Tuner, Touch Screen, DVR, Backup camera |
|
Warranty |
1 Year |
|
Certification |
CE, FCC, RoHS |
|
Place of Origin |
China |
|
Brand Name |
reako |
|
Model Number |
RK-A709,RK-A708,RK-A710 |
|
Operation System |
Android 10.0 |
|
GPS |
Built-in GPS Navigation System |
|
Product name |
Car Radio GPS |
|
Screen |
HD 1024*600 Capacitive Touch Screen |
|
Support |
Original Steering Wheel Control |
|
CPU |
Quad Core, 8 core |
|
Mirror link |
IPHONE ANDROID MOBILE PHONE |
|
ROM |
16GB, 32GB, 64GB, 128GB (optional) |
|
RAM |
1GB, 2GB, 4GB, 6GB (optional) |
|
OSD Language |
Multi-language |
1.Introduction to the Android platform
• CPU: snapdragon 625 (MSM8953) 8 core A53, clocked at 2.0GHz, 64bit processor
• Process: 14nm LPP
• GPU: Adreno 506 (650MHz)
• Storage: EMMC 5.1, capacity 32GB (default) / 64G
• Save: LPDDR3, capacity 2GB (default) / 4G
• Supports 3 major satellite systems simultaneously: GPS, Beidou and Glonass
• BT: BT4.1
• SD card: 1 way SD 3.0 (maximum support 128GB)
• USB: Maximum support for 4 USB 2.0
• System: Android 9.0
• Resolution: 1280*480
• Video: Support 4K Ultra HD video playback, H.264 (AVC), H.265 (HEVC)
2.Full Netcom 4G
• Support full Netcom 4G network: LTE Cat 7 (downstream, maximum 300Mbps; uplink, maximum 100Mbps)
•Eurasian version of the frequency band: B1, B3, B5, B7, B8, B38, B39, B40, B41
• North American version of the band: B2, B4, B5, B7, B8, B38, B41
• Eurasia version completely covers the domestic 3 major carrier networks
3.Wifi specification
• Support dual-band WIFI
• Frequency: 2.4G and 5G
• Frequency range: 2.4~2.496GHz, 4.9~5.85GHz • Rate: up to 433 Mbps (5G)
• Network standard: IEEE 802.11a/b/g/n/ac
• Support WIFI direct
4.Bluetooth specification
• Bluetooth version: 4.1+ BR/EDR+BLE• Protocol: HFP A2DP AVRCP SPP• Supports Bluetooth-WIFI coexistence operation • Maximum transmit power: 9dBm
• Maximum receiving sensitivity: -91dBm
• Transmission distance: <10 meters
5.GNSS specifications
• Satellite system: GPS / Beidou / Glonass (GLONASS)
• frequency:
GPS 1575MHz
Glonass 1601.7MHz
Beidou 1561MHz
• Channel: 22 (simultaneous tracking), 66 (search)
• Tracking sensitivity: -160dBm
• Hot start time: <5 seconds
• Cold start time: <35 seconds
• Positioning accuracy: <3 meters
6.Benz platform
• Support 3 major systems: NTG4.0, NTG4.5 (NTG4.7) and NTG5.0 (NTG5.1, NTG5.2)
• Support original car AUX automatic switching (NTG4.0 does not support)
• NTG4.5-4.7: Support original car AUX activation function
• NTG5.0-5.2: Support AUX-USB and Bluetooth transmit transmission sound
