Piranha 5mm Flat Top LED White Red Green Blue Super Flux Led Diode
Piranha 5mm Flat Top LED White Red Green Blue Super Flux Led Diode
Piranha Smd Led Flat Top Series White/Red/Green/Blue Super Flux Led Diode
Absolute Maximum rating of Flat Top Piranha LED:(Ta=25°C)
| Parameter | Symbol | Value | Unit |
| Forward current | If | 30 | mA |
| Reverse Voltage | Vr | 5 | V |
| Power dissipation | Pd | 60 | mW |
| Operationg temperature | Top | -40∼+80 | °C |
| ESD(Human-body mode | -- | 2 | KV |
| Storage temperature | Tstg | -40∼+80 | °C |
| Peak pulsing current(1/8 duty f=1kHz | lfP | 125 | mA |
Electrical characteristics of Flat Top Piranha LED:(Ta=25°C)
| Parameter | Test condition | Symbol | Value | Unit | ||
| Min | Typ | Max | ||||
| color temperature | If=20mA | λd | 5000 | 6000 | K | |
| Forward voltage | If=20mA | Vf | 2.8 | 3.2 | v | |
| Luminous intensity | If=20mA | Iv | 3000 | 3500 | mcd | |
| Viewing angle at 50% lv | If=10mA | 2θ1/2 | 120 | Deg | ||
| Resverse current | Vr=5v | Ir | 10 | mA | ||
Feature of Flat Top Piranha LED:
1. Pb free product—RoHS compliant.
2. Low power consumption
3. High efficiency
4. Wide viewing angle
5. High intensity
6. High quality with competitive price.
Application of Flat Top Piranha LED:
1.Indoor and out door commercial light
2.LED backlighting and SMD type indicator
3.LED midule and LED strip light
4.Decoration light
5.Auto lamp
6.Car light
High-end entertainment places such as decorative lighting,
Various colors and lens types available.
Hot sales
Established Shenzhen XINMINGHONG CO.,LTD in 2004 with 100000 grand purification constant termperature and humidity anti-static production workshop,mainly produce various LED,including PCB ,bracket and TOP type directory.
LED for renowned customers around the word. As a team with 20 yeas of management experience in domestic packing enterprises,it witnessed the rapid development of LED industry, accumulated rich experience in LED R&D and packaging technology, formed a scientific management sytem.Our monthly production is over 5000KK pcs.
Our products are the result of experienced manufacture process, rigorous quality control and carefully selected raw material supplies. . The massive production due to the high quality demand and competitive price in LED industry.
XMH provides excellent sales service and strong technical supports to our customers.
Why choose us?
Q1: Are you a manufacturer or a trading company ?
A1: We're professional manufacturer of Chip SMD LED, with 100000 grand purification constant termperature and humidity anti-static production workshop,mainly produce various LED,including PCB ,bracket and TOP type directory. Our products have exported worldwidesince the year 2004.
Q2: How do you control the quality ?
A2: We have perfect QC system (IQC, IPQC, FQC, OQC team), professional product engineers and continuous improvement system.
Q3: Is there any discount for bulk order?
A3: Yes, if you need bulk order or you want customized products, we can provide wholesale price.
Q4: How to choose LED light source ?
A4: Lumens(LM), light efficency(LM/W), life span((hrs) are very important factors when choosing LED light source. The higher, the better. Besides, brand of LED chip, LED base and other materials will influence the product reliability.
Q5. How to proceed an order for led light?
A5: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
PACKAGE:
Single package size: 16.0*23.0cm
Package Type: 1000pcs / tube, 40bags / carton & According To The Request.
Inner packaging: Anti-static Bag Packaging
Outer packaging: Standard export carton packing.
DELIVERY TIME:
1-7 days after confirming order,detail delivery date should be decided according to
production season and order quantity.
