7 Kw Type 1 Ev Charger Wallbox Single Phase Smart Home Electric Car Charger Station
Evse 32A Single Phase Type 1 Ac Ev Charger Wallbox 7Kw Home Electric Car Charger Station Ev Charging Portable
SHYR-T04 Electric vehicle charging station is a Level 2 charging station that charges your vehicles much faster. With a charging station installed at home or your shop, you will not have to drive down to a public charging station to get your car charged. This can mean a long time wait. If you want to lower the cost of driving, get the EVC3AA0 for your home. It is portable and can be carried along to charge the car at another location.
FEATURES:
- The SHYR-T04 Electric Vehicle Charging Station generates from 7.2kW to 7.7kW of power output, 8 times faster than Level 1. It is a 30 amp Level 2 charger that gets the vehicle charged rapidly.
- This single phase standard home charging station is non-networked and requires no special activation.
- This NEMA 4 rated charging station and can be installed indoors or outdoors.
- It is engineered for use in extreme climates where temperatures can range from -22F to 122F.
- The EVC3AA0 features a Universal J1772 Cable Connection. The J1772 plug was specifically designed for electric car charging.
- This Universal SAE J1772 charger can service all models of electric vehicles and plug-in hybrid electric vehicles. You will need an adaptor to charge a TESLA vehicle.
- This model includes optional Hardwire and Electrical. You can mount it to the wall or a pedestal. Modern compact design ensures safe management of the charging cable.
- You can plug this unit into a 240V outlet in your home using its NEMA 6-50 Plug.
- This model is equipped with an 18 or 25 ft charging cable for maximum user flexibility. The device is compatible with all charging station cables. The spring-loaded tether suspends the cable for easy drawback.
- You may mount the unit on a wall near the garage or outside near the driveway to best meet your specific needs.
- This Electric Vehicle Charging Station can be hardwired by a professional electrician.
- This EVC3AA0 Electric Vehicle Charging Station is UL/cUL listed for safety certification. The EvoReel with cable is ETL certified.
| Power Suppply | 3P+N+PE |
| Rated Voltage | 400VAC±10%(50Hz±5Hz) |
| Output voltage | 400VAC±20% |
| Output current | 16A/32A |
| Output power | 11KW/22KW |
| Electric energy measurement | Accuracy Class 1 energy meter |
| Connector Type | Type 1, Type 2, GB/T |
| Cable length | 5m (Custom) |
| Protection functions | Over voltage/under voltage protection, over current/short circuit protection, over/under temperature protection, lightning protection, emergency stop protection, RCD Type A and DC 6mA RCD leakage protection. |
| Communication | Ethernet/WIFI/4G LTE |
| Protocol | OCPP-1.6 (JSON) |
| HMI | 4.3 inch LCD |
| Insulation resistance | 1000VDC≥10MΩ |
| Dielectric Strength | AC2500≤10mA(input/output to ground) |
| Connector type | IEC 62196-2 |
| Standards | IEC 61851-1, IEC 62196-1/2 |
| Ingress Protection(IP/IK rating) | IP55 |
| Installation method | wall mount/Floor standing |
| Shell material | (PC+ABS)-Blend |
| Product Dimension | 300mm*420mm*153.8mm |
| Operating Temperature | -30℃-60℃ |
| Storage Temperature | -40℃-80℃ |
| Altitude | ≤2000m |
| Operating Humidity | ≤95%, non-condensing |
Such kind smart wall box is widely used by our clients just like our portable evchargers.You can use anytime you want and charger your car faster than common3.7kw protable charger in public place
