M10 EPDM Brake Hose Synthetic High Pressure Rubber Brake Hose
Synthetic Rubber M10 High Pressure Flexible Rubber EPDM Brake Hose Replacement For Sale
Introduce:
High pressure auto hose is made of excellent oil-resistant and anti-aging rubber. The reinforcement is smooth finish. The hose made in conformity with GB16897-2010 SAE J1401 DOT. Working temperature range is -40℉ to +212℉ (-40℃ to +100℃).
| Material | EPDM Rubber |
| Diameter | 1/8",3/16",etc |
| Function | Transfer pressure in hydraulic system |
| End Fitting | Steel with white zinc |
| Standard | SAE J1401 |
| Bursting pressure | ≥55MPa |
| Tensile strength | ≥1600N |
| Anti-flexure fatigue life | >35H |
| Low expansion meets |
6.9MPa≦0.33cm3/m 10.3MPa≦0.42cm3/m |
Specification:
| NO. | Inner diameter | Outer diameter | Burst Pressure(Mpa) | Expansion Amount (ml/m) | Flexural fatigue test | Low temperature ℃ | Pulse Resistance 0-22Mpa | Ozone resistant 50±5pphm.40℃ | |
| 6.9Mpa | 10.3Mpa | ||||||||
| RBRH-A | 3.2±0.1mm | 10.5±0.2mm | ≥55 | ≤1.15 | ≥35h | -55 | 150times | 70±2h | |
| RBRH-B | 3.2±0.2mm | 10.5±0.2mm | ≥49 | ≤0.54 | ≤0.69 | ≥35h | -40 | 150times | 70±2h |
| RBRH-C | 3.2±0.2mm | 10.5±0.2mm | ≥49 | ≤1.08 | ≤1.38 | ≥35h | -40 | 150times | 70±2h |
Application:
Hydraulic rubber EPDM brake hose act as a pressure transmission for automotive hydraulic brake system Used for Cars, motorcycles, light trucks and other Light Heavy-Duty vehicles for hydraulic brake system.
Characteristic:
- High pressure resistance, lower volumetric expansion, flexibility, small bend radius,
- Aging resistance, oil resistance, cold resistance and long lifespan
- Temperature: -40℃ (-40 ℉ ) to +121℃ (+250 ℉ )
