CQC 25 Colours Nylon Motorcycle Braided Hoses SS Wire Braided Brake Line
Highest temp resistance Nylon Brake Hose Stainless steel wire braided Brake line
Description:
The Stainless Steel Braided Nylon Brake Hose Lines are made from high quality 304 grade stainless steel.
With a nylon inner hose it means our stainless steel braided nylon brake hose lines are very resistant to
expansion under pressure and will not degrade from exposure to brake fluid.Finally our stainless steel
braided nylon brake hose lines are then covered in a abrasion resistant PVC/PU coating to protect the
hose against chaffing .The stainless steel outer braid offers excellent resistance to heat,abrasion and
mechanical damage and wll not absorb oil and fuel into its brading ,thus eliminating weight gain .
Construction:
| Inner Hose | Nylon Flexible Hose |
| Strength | 304 Stainless Steel Wire |
| Cover | PVC/PU,25 Colours |
Application:
Used for hydraulic brake system .
Feature:
Results in a firmer brake pedal. Improved brake pedal ”feeling” and better brake modulation.
Diffusion tight, means no more water in the brake fluid.
Age constant, (rubber gets dry and cracks during time) is compatible with
all brake and clutch fluids.
Sepcification
| Product Name | Material | Stainless Steel Type | I.D(mm) | O.D(mm) | W.P(PSI) | B.P(PSI) | Temp(℃) |
| Modified Nylon Brake Hose | Modified Nylon lnner Hose | 201 | 3.2 | 7.5 | 4660 | 8000 | -20～80 |
| PA 12 Recycled Black Nylon Brake Hose |
PA 12 Recycled Black Nylon lnner
Hose
|
304 | 3.2 | 7.5 | 4660 | 14000 | -20～100 |
| PA 12 Recycled White Nylon Brake Hose | PA 12 Recycled White Nylon lnner Hose | 304 | 3.2 | 7.5 | 4660 | 14000 | -20～100 |
| PA 12 Raw Material White Brake Hose | PA 12 Raw Material White inner Hose | 304 | 3.2 | 7.5 | 4660 | 14000 | -40～100 |
Hengshui Brake Hose Machinery Co.,Ltd is located in Hengshui City.Hebei Province.It was founded in
2005.Its specializes in R&D,production and sales of brake hose,brake steel throat,nylor resin reinforced
pipe,hydraulic hose of construction machinery,disc brake and other products for automobiles and
motorcycles for more than 10 years.
The company has a variety of products,complete specificationsand can be customized accordingto
customer requirements.we master abundant mature technology on the braiding,coating and crimping.
Now we can producing the PTEF brake hose20,000meters and assembly brake hose 5000 pcs per day.
