Dust Proof SAW Touch Screen , 17 Inch Touch Panel For Indoor Outdoor
17 Inch SAW Touch Screen Panel Dust Proof Kiosk Indoor Outdoor
SAW Touch Screen Main Features
- KeeTouch SAW touch technology, accurate touch, free of drift
- Fast response time 5-10ms, The SAW Touch Screen has perfect touch experience
- With tempered glass, vandal proof and dust proof
- With aluminum frame, dust proof is available
- the SAW Touch screen has 90% high transparency, superior image clarity
- Activated by finger, gloved hand, leather or soft stylus
- USB and RS232 interfaces, support Windows7, Windows8, Vista, XP, Mac, Linux, Android
- Other sizes are available (7’’- 43’’)
SAW Touch Screen Specifications
| Item | Contents |
|
Model No. |
KAL-0170-6BP-AL |
| Housing | Aluminum |
| Outside Dimensions | 389±1.5mm(L)×321±1mm(W)×8.8±0.5mm(H) |
| Active Area | 340±1mm(L)×272±1mm(W) |
| Aspect Ratio | 5:4 |
| Drawing | pls contact us |
| Size | 17 inch |
| Touch Activation Force | No minimum touch pressure required |
| Number of touch points | 1 touch points |
| Driver free | HID* compatible |
| Linearity Deviation | ±1mm |
| Response Time | 5-10ms |
| Light Transmission | 100% without glass |
| Operate System Support | Windows®7,Windows®8,Vista,XP,Mac® OS,Linux,Android |
| Temperature | operating:-20°C ~ 70°C |
| storage:-40°C ~ 85°C | |
| Humidity | operating:10% ~ 90% |
| storage: 10% ~ 90% | |
| Certifications | FCC , CE, RoHS |
| Operating Environment | Indoor and outdoor |
| Applicative Screen | LED,LCD,PDP etc. |
Applications
Widely used in industries such as retail, gaming, kiosk, self-service, finance, transit, conference, education, healthcare, public service, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.
FAQ
1. Are you a manufacturer?
Yes, KeeTouch is a professional touch product manufacturer for over 16 years, located in Shenzhen, China.
2. What’s your MOQ for the SAW Touch Screen?
Our minimum order quantity is 1pc only.
3. What is your warranty period for the SAW Touch Screen?
Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional).
4. Can you produce for the SAW Touch Screen according to the customer's requirements?
Sure, with 40+ Professional R & D engineers, OEM and ODM are offered.
5. What is your payment method?
We can accept T/T, Western Union, Paypal, Pay Later, Credit card, Boleto, e-Checking and Alipay. ( L/C can be negotiable. )
6. What is your delivery time for the SAW Touch Screen?
3-5 work days for inventory orders, 7-15 business days for bulk production.
