IP65 8 Inch TFT LCD Monitor , High Brightness Touch Screen Monitor 1024x768
8 Inch High Brightness Touch Monitor IP65 Waterproof 1024x768 Resolution
High Brightness Touch Monitor Main Features
- Anti-glare, vandal-proof functions
- PCAP multi touch panel, high-sensitivity and fast-response
- High quality high brightness touch monitor with full viewing angle
- High brightness, visible under direct sunlight, 1000 - 2000 nits are optional
- Pure flat high brightness touch monitor, IP65 surface waterproof
- HDMI + VGA interfaces,USB for touch
- Operation system: XP,WIN7,WIN8,WIN10
- Wide range of sizes are available (8’’- 43’’)
High Brightness Touch Monitor Specifications
| Complete Machine | ||
| Model No. | KOT-0080U-CA4PH (P/N:KOT-008C-005) | |
| Series | OT | |
| Display Type | 4:3 Ratio 8" TFT-LCD | |
| Active Area | 163*122.5(mm) | |
| Monitor Dimensions (W*H*D) | 214*177*40.7(mm) | |
| Suggested Resolution | 1024*768 @ 60Hz | |
| Support Colors | 16.2M | |
| Brightness (Typ.) | Pure LCD Panel | ≥1000cd/m2 |
| With Touch Monitor | ≥850cd/m2 | |
| Response Time (Typ.) | 16ms | |
| Viewing Angle(Typ.at CR＞10)) | Horizontal(left/right) | 89°/89° |
| Vertical(up/down) | 89°/89° | |
| Contrast Ratio (Typ.) | 1000:1 | |
| Video Input | VGA/HDMI | |
| Frequency (H/V) | 30～80KHz / 60～75Hz | |
| Power Supply |
Type: External brick Display voltage: DC 12V±5% 3.3A Input (line) voltage: 100-240 VAC, 50-60 Hz |
|
| Environment | Operating Temp. | -15～50°C |
| Operating RH | 20%～80% | |
| Storage Temp. | -20～60°C | |
| Storage RH | 10%～90% | |
| MTBF | ≥ 30,000 Hours | |
| LED Back Light Life (Typ.) | ≥ 30,000 Hours | |
| Power Consumption | Standby Power: ≤1.5W / Operating Power: ≤13W | |
| Mount Interface | Mount bracket, horizontal or vertical mount | |
| OSD Control | Buttons | AUTO,+,POWER,-,MENU |
| Function | Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset | |
| Agency approvals | CCC, UL, FCC, CE, CB, RoHS | |
| Regular Warranty | 1 year | |
| Touch Screen | |
| Touch Type | 8" capacitive touch screens |
| Touch input | USB |
| Response Time | ≤10ms |
| Hardness | 6H |
| Light Transmittance | >80% |
| Support System |
Multi-Touch : WIN7,WIN8,WIN10 Single Touch : XP |
| Touch Test | ≥ 50,000,000 次 |
| Input Voltage | DC 5V±5% |
NOTE :
① The display SPEC. are adjusted according to the selected LCD screen and touch screen
② The support system is adjusted according the specific system and version.
High Brightness Touch Monitor Mechanical Dimensions
Applications
KeeTouch products are widely used in industries such as retail, gaming, kiosk, self-service, finance, transit, conference, education, healthcare, public service, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.
FAQ
1. Are you a manufacturer?
Yes, KeeTouch is a professional touch product manufacturer for over 16 years, located in Shenzhen, China.
2. What’s your MOQ for the high brightness touch monitor?
Our minimum order quantity is 1pc only.
3. What is your warranty period for the high brightness touch monitor?
Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional).
4. Can you produce the High Brightness Touch Monitor according to the customer's requirements?
Sure, with 40+ Professional R & D engineers, OEM and ODM are offered.
5. What is your delivery time?
3-5 work days for inventory orders, 7-15 business days for bulk production.
