Anti Glare SAW Touch Screen 10.4 Inch Water Proof Anti Vandal
10.4 Inch SAW Touch Screen ≤10ms Response Time 90% Light Transmission
SAW Touch Screen Main Features
-
KeeTouch SAW touch panel, accurate touch, quick response
-
Anti-vandal, anti-glare and water-proof SAW touch screen
-
High light transmission, high-quality image SAW touch screen
-
USB/RS232 interfaces, support Windows7, Windows8, Vista, XP, Mac, Linux, Android
-
Other sizes are optional (7’’- 32’’)
SAW Touch Screen Specifications
| Complete Machine | ||
| Model No. | KAL-0104-4B-PRE2 | |
| Touch Medium | Finger, gloved hand, rubber soft pen etc. | |
| Sizes | 10.4 Inch | |
| Resolution | 4096*4096, Z-axis 256 | |
| Touch Activation Force | ＜80g | |
| Controller | KCA-URO1L-R2G | |
| Controller Interface | USB & RS232 | |
| Response Time | ≤10ms | |
| Transmission | 90% | |
| Temperature | Operation Temp:-20℃ to +60℃ | |
| Storage Temp:-40℃ to +70℃ | ||
| Humidity | 40℃@90%RH,non-condensing | |
| Operation Altitude | 3000m | |
| Electrostatic Protection | Per EN 61000-4-2, 1995 : | |
| (8 kV air / 4 kV contact discharges). | ||
| Agency Approval | FCC,CE,UL,RoHS | |
| Surface Durability | Optical glass surface, Mohs' hardness rating : 7. | |
| Life Performance | More than 50 million touches in one location. | |
| (Tested by a stylus similar as finger). | ||
SAW Touch Screen Mechanical Dimensions
Applications
KeeTouch products are widely used in industries such as retail, gaming, kiosk, self-service, finance, transit, conference, education, healthcare, public service, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.
FAQ
1. Are you a manufacturer?
Yes, KeeTouch is a professional touch product manufacturer for over 16 years, located in Shenzhen, China.
2. What’s your MOQ for the SAW touch screen?
Our minimum order quantity is 1pc only.
3. What is your warranty period for the SAW touch screen?
Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional).
4. Can you produce the SAW touch screen according to the customer's requirements?
Sure, with 40+ Professional R & D engineers, OEM and ODM are welcomed.
5. What is your payment method?
We can accept T/T, Western Union, Paypal, Pay Later, Credit card, Boleto, e-Checking and Alipay. ( L/C can be negotiable. )
6. What is your delivery time?
3-5 work days for inventory orders, 7-15 business days for bulk production.
