Industrial 21.5 Inch PCAP Touch Screen Monitor Full HD 1080P
Industrial 21.5 Inch PCAP Touch Screen Monitor Full HD 1080P
PCAP Touch Monitor Main Features
-
21.5'' PCAP touch monitor belongs to industrial grade , bring customer high quality touch experience
-
Come with Full HD 1080P Touch Panel
-
IP65 front surface waterproof function
-
Come with DVI, VGA and USB Input
-
Mount Interface: VESA 75mm and 100mm, mount bracket, horizontal or vertical mount
-
Support system: XP,WIN7,WIN8,WIN10, Linux, Android
-
Other sizes are available (7 inch- 43 inch)
-
Passed the CCC, ETL, FCC, CE, CB, RoHS certificates
PCAP Touch Monitor Specifications
| Complete Machine | ||
| Model No. | KOT-0215U-CA4P (P/N:KOT-215P-014) | |
| Series | OT | |
| Display Type | 16:9 Ratio 21.5" TFT-LCD | |
| Active Area | 476.6*269 (mm) | |
| Monitor Dimensions (W*H*D) | 512.1*307.3*47(mm) | |
| Suggested Resolution | 1920*1080 @ 60Hz | |
| Support Colors | 16.7M | |
| Brightness (Typ.) | Pure LCD Panel | 250cd/m2 |
| With Touch Monitor and Peep-proof protection film | 127cd/m2 | |
| Response Time (Typ.) | 5ms | |
| Viewing Angle(Typ.at CR＞10)) | Horizontal(left/right) | 85°/85° |
| Vertical(up/down) | 80°/80° | |
| Contrast Ratio (Typ.) | 1000:1 | |
| Video Input | VGADVI | |
| Frequency (H/V) | 37.9～80KHz / 60～75Hz | |
| Power Supply |
Type: External brick Display voltage: DC 12V±5% Input (line) voltage: 100-240 VAC, 50-60 Hz |
|
| Environment | Operating Temp. | 0～50°C |
| Operating RH | 20%～80% | |
| Storage Temp. | -20～60°C | |
| Storage RH | 10%～90% | |
| MTBF | ≥30,000 Hours | |
| LED Back Light Life (Typ.) | ≥30,000 Hours | |
| Weight(N.W/G.W) | 5.6Kg(1pcs)/13.4Kg(2pcs in one package) | |
| Package dimensions | 605*400*195(mm)(2pcs in one package) | |
| Power Consumption | Standby Power: ≤1.5W / Operating Power: ≤30W | |
| Mount Interface |
1.VESA 75mm and 100mm 2.Mount bracket, horizontal or vertical mount |
|
| OSD Control | Buttons | AUTO,+,POWER,-,MENU |
| Function | Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset | |
| Agency approvals | CCC, UL, FCC, CE, CB, RoHS | |
| Regular Warranty | 1 year | |
| Touch Screen | |
| Touch Type | 21.5" Capacitive touch screens |
| Touch input | USB |
| Response Time | ≤10ms |
| Hardness | 6H |
| Light Transmittance | ≥85% |
| Support System | XP,WIN7,WIN8,WIN10,Linux,Android |
| Active Area | 479.04*270.51(mm) |
| Thickness | 4.3±0.3(mm) |
| Touch Test | ≥50,000,000 times |
| Input Voltage | DC 5V±5% |
NOTE :
① The display SPEC. are adjusted according to the selected LCD screen and touch screen
② The support system is adjusted according the specific system and version.
| Peep-proof protection film | |
| Type | Peep-proof protection film |
| Guard against peep angle | Horizontal(left/right) 40°±5° |
| Thickness | 570±50(um) |
| Light Transmittance | ≥60%±5% |
PCAP Touch Monitor Mechanical Dimensions
Applications
KeeTouch products are widely used in industries such as retail, gaming, kiosk, self-service, finance, transit, conference, education, healthcare, public service, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.
FAQ
1. What’s your MOQ?
Our minimum order quantity is 1pc only.
2. What package do you provide?
Our package usually is carton.
3. What is your warranty period for the PCAP touch monitor?
Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional).
4. Can you produce the PCAP touch monitor according to the customer's requirements?
Sure, with 40+ Professional R & D engineers, OEM and ODM are welcomed.
5. Payment methods and payment terms?
Payment Methods: T/T, Paypal and Western Union, etc.
6. What are the shipping ways?
DHL, UPS, FedEx, TNT, EMS, Air Freight, Sea Freight
