Sunlight Readable High Brightness Touch Monitor Screen 27" For Banking ATMs
27" Inch High Brightness Touch Monitor Daylight Readable For Banking ATMs
High Brightness Touch Monitor Main Features
-
Multi-points PCAP touch panel, high sensitive and fast-response
-
Anti-glare,vandal-proof and dust-proof, IP65 surface waterproof function
-
High brightness sunlight readable,1000 - 2000 nits optional
-
Support Resistive touch, SAW touch , IR touch, Capacitive touch.
-
Compatible with various industrial systems/application.
High Brightness Touch Monitor Specifications
| Complete Machine | ||
| Model No. | KOT-0270U-CA4PH (P/N:KOT-270P-005-01) | |
| Series | OT | |
| Display Type | 16:9 Ratio 27" TFT-LCD | |
| Active Area | 597.6*336.15(mm) | |
| Monitor Dimensions (W*H*D) | 655.9*394.4*87(mm) | |
| Suggested Resolution | 1920*1080 @ 60Hz | |
| Support Colors | 16.7M | |
| Brightness (Typ.) | Pure LCD Panel | 1000cd/m2 |
| With Touch Monitor | 850cd/m2 | |
| Response Time (Typ.) | 12ms | |
| Viewing Angle(Typ.at CR＞10)) | Horizontal(left/right) | 89°/89° |
| Vertical(up/down) | 89°/89° | |
| Contrast Ratio (Typ.) | 3000:1 | |
| Video Input | VGA/HDMI | |
| Frequency (H/V) | 30～80KHz / 50～76Hz | |
| Power Supply |
Type: External brick Display voltage: DC 24V 7A ±5% Input (line) voltage: 100-240 VAC, 50-60 Hz |
|
| Environment | Operating Temp. | 0～50°C |
| Operating RH | 20%～80% | |
| Storage Temp. | -20～60°C | |
| Storage RH | 10%～90% | |
| MTBF | 30,000 Hours | |
| LED Back Light Life (Typ.) | 30,000 Hours | |
| Power Consumption | Standby Power: 2.5W / Operating Power: ≤120W | |
| Mount Interface |
1. VESA 75mm and 100mm 2. Mount bracket, horizontal or vertical mount |
|
| Weight(N.W/G.W) | 12.5Kg/17.35Kg | |
| Package dimensions | 80.5*23.3*55.3cm | |
| OSD Control | Buttons | AUTO,+,POWER,-,MENU |
| Function | Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset | |
| Agency approvals | CCC, ETL, FCC, CE, CB, RoHS | |
| Touch screen Type | 27”Projected Capacitive Touchscreen | |
| Touch System Interface | USB | |
| Support System | 10 points in win7,Win xp 1 point | |
| Regular Warranty | 1 year | |
NOTE :
① The display SPEC. are adjusted according to the selected LCD screen and touch screen
② The support system is adjusted according the specific system and version.
High Brightness Touch Monitor Mechanical Dimensions
Applications
1. Business Organizations: supermarket, large-scale shopping malls, exclusive agency, chain shops, large-scale sales, star-rated hotels, restaurants, travel agencies, pharmacy.
2. Financial Organizations: Banks, negotiable securities, funds, insurance companies;
3. Non-profit Organizations: Telecommunications, post offices, hospital, schools;
4. Entertainments: Movie theaters, fitness halls, country clubs, clubs, massage rooms, bars, cafes, Internet bars, beauty shops, golf course.
FAQ
1. What’s your MOQ?
Our minimum order quantity is 1pc only.
2. What is your warranty period?
Our regular warranty is 12 months for all the products, with 2-3 years Warranty (optional).
3. What is your delivery time?
3-5 work days for inventory orders, 7-15 business days for bulk production.
4. What package do you provide?
Our package usually is carton.
5. Do you have stock?
Yes, we have a large quantity of stock for our regular model products.
6. Do you give any discount?
We will do utmost to support you with the competitive price, also good service will be offered.
