Industrial 17in Touch Screen Monitor Infrared Dust Proof With VGA Interface
Industrial 17 Inch IR Touch Screen Monitor 1280*1024 with Waterproof
Infrared Touch Monitor Main Features
-
Infrared multi touch panel, high quality touch experience
-
IP65 grade water-proof, dust-proof for front panel
-
CCC, ETL, FCC, CE, CB, RoHS certificate
- VGA interface,USB for touch
- Aluminum alloy shell,good mechanical properties,better performance of heat dissipation
- CCC, ETL, FCC, CE, CB, RoHS certificate.
- Support system: XP, WIN7, WIN8, Linux
- Other sizes can be offered (7’’- 43’’)
Infrared Touch Monitor Specifications
| Complete Machine | ||
| Model No. | KOT-0170U-IR4W (P/N:KOT-170C-011) | |
| Series | OT | |
| Display Type | 5:4 Ratio 17" TFT-LCD | |
| Active Area | 337.9*270.3(mm) | |
| Monitor Dimensions (W*H*D) | 381*313*48.5(mm) | |
| Suggested Resolution | 1280*1024 @ 60Hz | |
| Support Colors | 16.7M | |
| Brightness (Typ.) | Pure LCD Panel | 250cd/m2 |
| With Touch Monitor | 225cd/m2 | |
| Response Time (Typ.) | 5ms | |
| Viewing Angle(Typ.at CR＞10)) | Horizontal(left/right) | 85°/85° |
| Vertical(up/down) | 80°/80° | |
| Contrast Ratio (Typ.) | 1000:1 | |
| Video Input | VGA | |
| Frequency (H/V) | 37.8～68.4KHz /50～76Hz | |
| Power Supply |
Type: External brick Display voltage: DC 12V±5% Input (line) voltage: 100-240 VAC, 50-60 Hz |
|
| Environment | Operating Temp. | 0～50°C |
| Operating RH | 20%～80% | |
| Storage Temp. | -20～60°C | |
| Storage RH | 10%～90% | |
| MTBF | ≥30,000 Hours | |
| LED Back Light Life (Typ.) | ≥30,000 Hours | |
| Weight(N.W/G.W) | 4.7Kg(1pcs)/10.4Kg(2pcs in one package) | |
| Package dimensions | 466*185*403(mm)(2pcs in one package) | |
| Power Consumption | Standby Power: ≤1.5W / Operating Power: ≤20W | |
| Mount Interface |
1.VESA 75mm and 100mm 2.Mount bracket, horizontal or vertical mount |
|
| OSD Control | Buttons | AUTO,+,POWER,-,MENU |
| Function | Brightness, Contrast Ratio, Auto-adjust, Phase, Clock, H/V Location, Languages, Function, Reset | |
| Agency approvals | CCC, UL, FCC, CE, CB, RoHS | |
| Regular Warranty | 1 year | |
| Touch Screen | |
| Touch Type | 17" Infrared touch screen |
| Touch input | USB |
| Response Time | ≤32ms |
| Hardness | 7H |
| Light Transmittance | ≥90% |
| Support System | XP,WIN7,WIN8,WIN10 |
| Active Area | 339*271(mm) |
| Thickness | 9±1(mm) |
| Touch Test | ≥50,000,000 times |
| Input Voltage | DC 5V±5% |
Infrared Touch Monitor Mechanical Dimensions
Applications
KeeTouch products are widely used in industries such as retail, gaming, kiosk, self-service, finance, transit, conference, education, healthcare, public service, e-commerce, hotels, restaurants, travel service, payment systems, museums, exhibitions, smart home, subways, railway stations, control and operation systems, airports, entertainments, etc.
FAQ
1. Are you a manufacturer?
Yes, KeeTouch is a professional touch product manufacturer for over 16 years, located in Shenzhen, China.
2. What’s your MOQ for infrared touch screen?
Our minimum order quantity is 1pc only.
3. Do you give any discount?
We will do utmost to support you with the competitive price, also good service will be offered.
4. Do you support customization?
Yes. We are the manufacturer of Industrial Touch Screen and Touch Monitor. And have professional R&D Team, could customized the touch monitor according to your requirement.
5. What is your payment method?
We can accept T/T, Western Union, Paypal, Pay Later, Credit card and Alipay. ( L/C can be negotiable. )
6. What is your delivery time for the infrared touch monitor?
3-5 work days for inventory orders, 7-15 business days for bulk production.
